11.1.2 Упаковочный лист

Рис.123 Упаковочный лист для котлов с указанием класса энергоэффективности отопления помещений данного

комплекта

AD-3000743-01

‘I’

%( - ‘I’ ) x 0.1 = ±

%(‘III’ x + ‘IV’ x ) x 0.9 x ( /100) x = +

(1)

A* = 0.95, A = 0.91,

B = 0.86, C = 0.83,

D - G = 0.81

%( - ‘I’ ) x ‘II’ = +

%0.5 x 0.5 x = -

<30%

G F E D C B A A

+++

%+ (50 x ‘II’) =

from ﬁ che of solar device

Solar contribution AND Supplementary heat pump

Solar contribution

The energy efﬁ ciency of the package of products provided for in this ﬁ che may not correspond to its actual energy efﬁ ciency once installed

in a building, as this efﬁ ciency is inﬂ uenced by further factors such as heat loss in the distribution system and the dimensioning of the

products in relation to building size and characteristics.

Boiler and supplementary heat pump installed with low temperature heat emitters at 35°C ?

Seasonal space heating energy efﬁ ciency class of package

Seasonal space heating energy efﬁ ciency of package

Seasonal space heating energy efﬁ ciency (in %)

Supplementary heat pump

Tank rating

Collector efﬁ ciency (in

Tank volume (in m³) Collector size (in m²)

Seasonal space heating energy efﬁ ciency (in %)

Supplementary boiler

Class I = 1%, Class II = 2%, Class III = 1.5%,

Class IV = 2%, Class V = 3%, Class VI = 4%,

Class VII = 3.5%, Class VIII = 5%

Temperature control

Seasonal space heating energy efﬁ ciency of boiler

(1) If tank rating is above A, use 0.95

select smaller value

from ﬁ che of heat pump

from ﬁ che of boiler

from ﬁ che of temperature control

11 Приложение

7725160 - v.01 - 12062019 AMC Pro 75
