Installation instructions en

26.2 Appliance dimensions

You will find the dimensions of the appliance here

26.3 Installation below a worktop

Observe the installation dimensions and the installation

instructions when installing below a worktop.

¡ To ventilate the appliance, the intermediate floor

must have a ventilation cut-out.

¡ The worktop must be secured to the built-in unit.

¡ Observe any available installation instructions for the

hob.

26.4 Installation underneath a hob

If the appliance is installed under a hob, the following

minimum dimensions must be adhered to (including

substructure, if applicable).

The minimum worktop thickness a is based on the

required minimum clearance ⁠.

Hob type a raised in mm a flush in mm b in mm

Induction hob 37 38 5

Full-surface induction hob 47 48 5

Gas hob 27 38 5

Electric hob 27 30 2
