8
English
Be careful of the hot nozzle.
Removing the front cover increases the
risk of burn with the bare hot nozzle.
Stripping paint
Q Mount an appropriate accessory.
Q Set a high air temperature.
Q Switch the tool on.
Q Direct the hot air onto the paint to be removed.
Q When the paint softens, scrape the paint away
using a hand scraper.
Do not strip metal window frames, as
the heat may be conducted onto the
glass and crack it. When stripping
other window frames, use the glass
protection nozzle.
Do not keep the tool directed at one
spot too long to prevent igniting the
surface.
Avoid collecting paint on the scraper
accessory, as it may ignite. If neces-
sary, carefully remove paint debris
from the scraper accessory using a
knife.
Stationary use
This tool can also be used in stationary mode.
Q Place the tool onto a stable workbench.
Q Secure the cable to prevent pulling the tool off the
workbench.
Q Carefully switch the tool on.
Make sure that the nozzle always
points away from you and any
bystanders.
Make sure not to drop anything into
the nozzle.
Cooling down
The nozzle and accessory become very hot during use.
Let them cool down before attempting to move or store
the tool.
Q To reduce the cooling time, switch the tool on at
the lowest air temperature setting and let it run for
a few minutes.
Q Switch the tool off and let it cool down for at least
30 minutes. Always place it vertical and standing.
When the inside of heat gun gets too
hot, the indication on the LCD blinks.
In that case, set the slide switch to
position 1 to cool down the tool.
After cooling down fully, restart the
operation.
If the LCD still blinks after the restart,
contact your local Makita Service
Center.
MAINTENANCE AND CLEANING
Attention: Before performing any
work on the equipment, pull the
power plug.
Maintenance
Q Your Power Tool has been designed to operate
over a long period of time with a minimum of
maintenance. Continuous satisfactory opera-
tion depends upon proper tool care and regular
cleaning.
Lubrication
Q Your power tool requires no additional lubrication.
Cleaning
Q To prevent overheating of the motor, keep the
ventilation slots of the machine clean and free
from dust and dirt.
Q Regularly clean the machine housing with a soft
cloth, preferably after each use. If the dirt does not
come off use a soft cloth moistened with soapy
water.
Never use solvents such as petrol,
alcohol, ammonia water, etc. These
solvents may damage the plastic
parts.
TECHNICAL DATA
Model No:
HG6531C HG6530V
Voltage 220-240V~50Hz 220-240V~50Hz
Power 2000W 2000W
Temperature
Air ow
I 50°C 200-550L/M
II 50-650°C 200-550L/M
I 50°C 500L/M
II
50-650°C
280L/M
III
50-650°C
550L/M
Overall length
257mm 257mm
Net weight
0.71kg 0.72kg
Default setting of the preset mode
No. Application name Temperature Air volume
1 FREE SET 1 250°C 5
2 FREE SET 2 500°C 5
3 SCRINKING 300°C 3
4 FORMING 250°C 4
5 SOLDERING COPPER 650°C 3
6 DRYING PAINT 650°C 5
7 PAINT STRIPPING 450°C 5
8 WELDING FLOOR FOIL 450°C 3
9 WELDING PPEPDM 280°C 3
10 WELDING HDPE 300°C 3
11 WELDING PP 320°C 3
12 WELDING PVC-U 340°C 3
13 WELDING ABS 360°C 3
14 WELDING PC 380°C 3
