Control panel view (2600 f1 and 3600 f1 models)

Use the buttons on the control panel to start or cancel a scan, and to turn the unit on and o.

1 32 54

Table 1-6 Control panel view (2600 f1 and 3600 f1 models)

Callout Icon Name Description

1 Cancel button Press this button to cancel a scan in progress.

2 Shortcut Select button Press this button to toggle through and select a scan shortcut

option:

● Scan to PDF

● Scan to JPEG (picture)

● Scan to Email

● Scan to Cloud

● Scan to USB (3600 f1 only)

The selected shortcut will be indicated by the corresponding

LED indicator.

NOTE: The settings of the shortcuts can be congured in the

HP Scan software.

3 Default/Duplex Toggle button Press this button to toggle between default (simplex or duplex)

and forced duplex scan.

4 Scan button Press this button to initiate a scan.

5 Power button and LED Press this button to turn on the scanner. Press and hold this

button for three seconds to turn o the scanner.
