2. Open a web browser, and in the address line, type the IP address or host name exactly as it displays on the

product control panel. Press the Enter key on the computer keyboard. The EWS opens.

Figure 2-9 Example of an IP address in a web browser

NOTE: If the web browser displays a message indicating that accessing the website might not be safe,

select the option to continue to the website. Accessing this website will not harm the computer.

3. Among the EWS top navigation tabs, click the Security tab.

4. In the left navigation pane, click Access Control.

5. Select Enable Access Control.

● If you want to use the current user account, click Edit to set a PIN code and select scanner features that

you want the current user account to access.

● If you want to create a new user account, click New. Enter an account name, set a PIN code, and then

select scanner features that you want this user account to access.

6. Click OK.

Once the access control has been set up, users cannot access the disabled scanner features and need to enter

the PIN to use the enabled scanner features.

Load originals

The following topics describe how to load originals into the input tray.

Document loading tips

Use the following tips to load originals correctly.

● The maximum capacity of the input tray is 60 sheets of 80 g/m

(24 lb) paper (2600 f1 and 3600 f1 models)

or 100 sheets of 80 g/m

(24 lb) paper (N4600 fnw1 and N6600 fnw1 models). When using heavier paper,

the maximum capacity is decreased.

TIP: Use the lines on the input tray paper guides to help you to not exceed the input tray capacity.

● Be sure that original documents are within these guidelines:

Table 2-6

Supported paper size and weight

Item Size

Width: 2600 f1 and 3600 f1 models: 89 to 216 mm (3.5 to 8.5 in)

N4600 fnw1 and N6600 fnw1 models: 105 to 216 mm (4.1 to 8.5 in)

Length: 2600 f1 and 3600 f1 models: 148 to 3100 mm (5.8 to 122 in)

N4600 fnw1 and N6600 fnw1 models: 148 to 5362 mm (5.8 to 211 in)

Weight:

2600 f1 models: 60 g/m

(16 lb) to 105 g/m

(28 lb)

3600 f1 models:49 g/m2 (13 lb) to 120 g/m2 (32 lb)

24 Chapter 2 Use the scanner
