14 English
Description of the device
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the illustrations, refer to the graphics page
Illustration A
1 Power switch with variable speed control
2 Rear handle
3 Unlocking button
4 Front handle
5 Upper shaft
6 Shaft coupling
7 Lower shaft
8 Motor casing
9 Switch for adjusting the working width
10 String guard
11 Cutting blade
12 Plant guard bracket
13 Cutting string
14 *Rechargeable battery pack
15 *Charger
16 Reel cover
17 Reel cover release
18 Cutting tool
a) String reel
b) Trimmer blade
19 Eye
20 Button for releasing the string
21 Type plate
22 Carrying belt (2.445-242.0)
* optional
Rechargeable battery pack
The device can be operated with a Kärcher 36 V Bat-
tery Power battery pack.
Installation
Installing the string guard
몇 WARNING
Blade on the string guard
Incision injuries
Install the string guard before using the device for the
first time.
몇 WARNING
Exposed string
Incision injuries
Never use the device without the string guard.
Illustration B
The string guard must face the operator.
1. Insert the string guard into the bracket.
2. Screw the string guard to the bracket.
Installing the plant guard bracket
1. Install the plant guard bracket.
Illustration C
Installing shaft
1. Connect the upper and lower shaft segments.
Illustration D
Installing the front handle
1. Screw the front handle to the upper shaft section at
the desired height.
Illustration E
Initial startup
Adjusting the string length
1. Use the switch to adjust the desired working width.
Illustration F
2. Press the button for releasing the string and pull the
string out of the string reel and up to the cutting
edge. If necessary, press the button several times.
Illustration G
Installing the battery pack
1. Push the battery pack into the mounting in the de-
vice until it audibly latches into place.
Illustration H
Operation
Bringing the plant guard into the operating
position
1. Pull out the plant guard before starting the mowing
process and put it back into operating position.
Illustration I
Inserting the carrying belt
1. Place the belt over one shoulder.
Illustration J
2. Push the hook of the carrying belt into the eyelet on
the shaft.
Working techniques
몇 CAUTION
Obstacles in the mowing area
Risk of injury and damage
Before starting mowing, check the work area for objects
that may be flung away, e.g. wires, stones, cords or
glass.
1. Press the unlocking button.
Illustration K
2. Press the power switch.
Danger due to flung objects. Keep a safe dis-
tance away.
Hand injuries from sharp cutting tool.
Pull: Quick release tab for carrying belt
