English

1. Connect the USB connector on the Y-cable to a USB port on your computer.

(optional) Connect the USB connector to another USB port for additional power if your computer’s

USB port does not provide enough power through the USB connector , resulting in the optical drive

not functioning properly.

NOTE:

• USB connector is only used for additional power, and cannot be used for data transfer

• If you are using a Blu-ray optical disc drive, please ensure to connect both USB connectors (

and ) to USB ports on your computer.

• You may need to use a USB extension cable (purchased separately) to connect the additional

USB connector if you do not have enough free USB ports on one side of the computer.

2. Connect the Y-cable to your optical drive.

NOTE: This connector and port may vary between models.

3. (For Windows only) Press the Eject button to open the optical drive tray.

Using the bundled Y-Cable

Models: SDRW-08D2S-U / SDRW-08D2S-U LITE / SDRW-08D6S-U / SDRW-08U5S-U / SDRW-08U7M-U /

SDRW-08U9M-U / SBC-06D2X-U / SBW-06D2X-U / SBW-06D5H-U / SDR-08B1-U
