Specifications

CPU

∙ Supports 12th Gen Intel® Core™, Pentium® Gold and

Celeron® Processors*

∙ Processor socket LGA1700

* Please go to www.msi.com to get the newest support status as new processors

are released.

Chipset Intel® Z690 Chipset

Memory

∙ 4x DDR5 memory slots, support up to 192GB*

▪ Supports JEDEC standard DDR5 4800/ 6400+ (OC) MHz

▪ Supports Intel® XMP 3.0 OC

▪ Supports Dual Controller Dual-Channel mode

▪ Supports non-ECC, un-buffered memory

*Please refer to www.msi.com for more information on compatible memory.

Expansion Slot

∙ 3x PCIe x16 slots

▪ PCI_E1 & PCI_E2 slots (From CPU)

▫ Support PCIe 5.0

▫ Support x16/ x0, x8/ x8

▪ PCI_E3 slot (From Z690 Chipset)

▫ Supports PCIe 3.0 x4

Multi-GPU ∙ Supports AMD® CrossFire™ Technology

Onboard Graphics

∙ 1x HDMI 2.1 with HDR port, supports a maximum

resolution of 4K 60Hz*

∙ 1x DisplayPort 1.4 port with HBR3, supports a maximum

resolution of 4K 60Hz*

*Available only on processors featuring integrated graphics.

** Graphics specifications may vary depending on the CPU installed.

Continued on next page
