Specifications

Continued from previous page

Internal Connectors

∙ 1x 24-pin ATX main power connector

∙ 2x 8-pin ATX 12V power connectors

∙ 6x SATA 6Gb/s connectors

∙ 5x M.2 slots (M-Key)

∙ 1x USB 3.2 Gen 2 10Gbps Type-C connector

∙ 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2

USB 3.2 Gen 1 5Gbps ports)

∙ 2x USB 2.0 Type-A connectors (supports additional 4 USB

2.0 ports)

∙ 1x 4-pin CPU fan connector

∙ 1x 4-pin water-pump fan connector

∙ 6x 4-pin system fan connectors

∙ 1x Front panel audio connector

∙ 2x System panel connectors

∙ 1x Chassis Intrusion connector

∙ 1x Clear CMOS jumper

∙ 1x TPM module connector

∙ 1x TBT connector (supports RTD3)

∙ 1x Tuning Controller connector

LED Features

∙ 1x EZ LED Control switch

∙ 4x EZ Debug LED

∙ 1x 2-Digit Debug Code LED

∙ 1x 4-pin RGB LED connector

∙ 2x 3-pin RAINBOW LED connectors

∙ 1x 3-pin CORSAIR LED connector

Continued on next page
