English 13
16 Steam lever
17 Unlocking button
18 Child lock
19 Steam hose
20 Steam Connector
21 Spotlight nozzle
22 Round brush (small)
23 **Round brush (large)
24 **Power nozzle
25 Crevice brush
26 Manual nozzle
27 Manual nozzle microfibre cover
28 Extension tubes (2 x)
29 Unlocking button
30 Floor nozzle
31 Hook and loop fastener
32 Microfibre floor cloth (1 x)
33 **Microfibre floor cloth (2 x)
34 **Carpet glider
35 Descaler
36 Steam pressure iron
37 Indicator light (orange) - heating
38 Steam switch (bottom)
39 Steam connector
**SC 4 Deluxe EasyFix Iron Premium
Installation
Installing accessories
1. Open the cover on the device socket.
Illustration B
2. Connect the steam connector to the device socket
so that the steam connector audibly engages.
Illustration B
3. Push the open end of the accessory onto the steam
gun so that the unlocking button on the steam gun
engages.
Illustration G
4. Push the open end of the accessory onto the spot-
light nozzle.
Illustration H
5. Connect the extension tubes with the steam gun.
a Push the 1st extension tube onto the steam gun
so that the unlocking button on the steam gun en-
gages.
The connection pipe is connected.
b Push the 2nd extension tube onto the
1st extension tube.
The connection pipes are connected.
Illustration I
6. Push the accessory and / or the floor nozzle onto the
free end of the extension tube.
Illustration J
The accessory is connected.
Disconnecting accessories
1. Move the child lock back.
The steam lever is locked.
2. Push the cover on the device socket down and dis-
connect the steam connector from the device sock-
et.
3. Press the unlocking button and pull the parts apart.
Illustration O
Operation
Filling water
The water reservoir can be removed at any time for fill-
ing or be filled directly at the device.
ATTENTION
Damage to the device
Unsuitable water can block the nozzles or damage the
water level indicator.
Do not fill in pure distilled water. Use a maximum of 50%
distilled water mixed with tap water.
Do not use condensation from the clothes dryer for fill-
ing.
Do not use collected rain water for filling.
Do not use cleaning agents or other additives (e.g.
scents) for filling.
Removing the water reservoir for filling
1. Pull the water reservoir vertically upwards.
Illustration C
2. Fill the water tank vertically with tap water or a mix-
ture of tap water and no more than 50% distilled wa-
ter.
3. Insert the water reservoir and press downwards until
it locks into place.
Filling the water reservoir directly on the device
1. Fill tap water or a mixture of tap water and no more
than 50% distilled water from a vessel into the filling
hole of the water reservoir up to the "MAX" mark.
Illustration D
Switching on the device
Note
If there is no or too little water in the steam boiler, the
water pump starts to run and pumps water from the wa-
ter reservoir into the steam boiler. The filling process
can take several minutes.
Note
The device briefly closes the valve every 60 seconds
causing an audible soft click. Closing prevents the valve
from clogging. This does not affect the steam output.
1. Place the device on a firm surface.
2. Insert the main plug into a socket.
3. Turn the selector switch from the OFF position to the
steam setting selection range.
Illustration E
The LED strip is in fading red.
4. The LED light lights up a continuous green after ap-
prox. 3 minutes.The device is ready for use.
Illustration F
5. Press the steam lever.
Illustration G
Steam leaks out.
Regulating the steam volume
The expelled steam volume is regulated using the se-
lector switch for steam volume. The selector switch has
three positions.
