ENGLISH

Overview

A - Tap-to-mute sensor

B - LED ring

C - Gain control knob

D - Multifunction button

*Supports both 3/8” and 5/8” thread sizes

Using with PC, Mac, PS5, or PS4

Connecting Headphones

Connect headphones to the headphone jack on the microphone for

microphone monitoring and playback audio.

Selecting a Microphone Polar Pattern

Push the multifunction button to switch between the microphone’s

two polar patterns, indicated by the LED ring.

Adjusting Microphone Gain

Muting the Microphone

Tap the top of the microphone to mute/unmute the microphone. The

LED ring will toggle to indicate the change in mute status.

Turning Microphone Monitoring On/O

To turn microphone monitoring on/o, hold the multifunction button

and tap the top of the microphone.

Installing the Mount Adapter

1. Remove both the thumb screw and nut from the microphone stand.

2. Remove the microphone stand from the microphone.

3. Align the mount adapter with the microphone mount holes and

secure the adapter with the thumb screw and nut.

E - Headphone output

F - USB-C port

G - USB-C to USB-A cable

H - Mount adapter*

Full to front

Cardioid

Omnidirectional

Front to full

LED RING SOUND DIRECTIONPOLAR PATTERN

HyperX NGENUITY Software

To customize lighting, download the HyperX NGENUITY software at :

hyperxgaming.com/ngenuity

Questions or Setup Issues?

Contact the HyperX support team or see user manual at:

hyperxgaming.com/support/microphones
