12 English

Trademarks

 Google Play™ and Android™ are trademarks or

registered trademarks of Google Inc.

 Apple

and App store

are trademarks or registered

trademarks of Apple Inc.

Environmental protection

The packing materials can be recycled. Please

dispose of packaging in accordance with the en-

vironmental regulations.

Electrical and electronic appliances contain valu-

able, recyclable materials and often components

such as batteries, rechargeable batteries or oil,

which - if handled or disposed of incorrectly - can

pose a potential danger to human health and the envi-

ronment. However, these components are required for

the correct operation of the appliance. Appliances

marked by this symbol are not allowed to be disposed

of together with the household rubbish.

Cleaning work producing in oily waste water, e.g.

washing engines, washing undercarriages etc.,

may only be performed at washing stations with an oil

separator.

Working with detergents may only be performed on

watertight surfaces with connection to the waste

water sewage system. Do not allow detergent to enter

waterways or the soil.

Extraction of water from public waterways is not

permitted in some countries.

Notes on the content materials (REACH)

Current information on content materials can be found

at: www.kaercher.de/REACH

Intended use

Use the high-pressure cleaner in private households

only.

The high-pressure cleaner is intended for cleaning ma-

chines, vehicles, buildings, tools, façades, terraces,

garden machines etc. using a high-pressure water jet.

Accessories and spare parts

Only use original accessories and original spare parts.

They ensure that the appliance will run fault-free and

safely.

Information on accessories and spare parts can be

found at www.kaercher.com.

Scope of delivery

The scope of delivery for the appliance is shown on the

packaging. Check the contents for completeness when

unpacking. If any accessories are missing or in the event

of any shipping damage, please notify your dealer.

Description of the device

The maximum amount of equipment is described in

these operating instructions. Depending on the model

used, there are differences in the scope of delivery (see

packaging).

For the illustrations, refer to the graphics page

Illustration A

Illustration B

1 Stand with carrying handle

2 Water connection with integrated sieve

3 Transport wheel

4 Visor

5 Hose guide

6 Trigger "0/OFF" / "I/ON"

7 Storage for spray lance

8 High-pressure hose

9 *Plug 'n' Clean detergent bottle

10 Storage / parking position for high-pressure gun

11 Transport handle, telescoping

12 Power Control spray lance dirt grinder for stubborn

dirt, pressure level: HARD

13 Vario Power Power Control spray lance for the most

common cleaning tasks, pressure levels: HARD /

MEDIUM / SOFT / MIX

14 Power Control high-pressure gun

15 Button for separating the high-pressure hose from

the high-pressure gun

16 High-pressure gun lever

17 Pressure indicator (0-MIX / 1-SOFT / 2-MEDIUM /

3-HARD)

18 High-pressure gun lock

19 Carrying handle

20 Hose holder

21 High pressure hose reel

22 Crank handle for hose reel

23 Type plate

24 Accessory compartment

25 Hook for net attachment

26 Accessory compartment net

27 Mains connection with mains plug

28 Water connection coupling

29 **Garden hose (fabric reinforced, diameter at least

1/2 inch (13 mm), length at least 7.5 m, with com-

mercially available quick coupling)

30 **KÄRCHER suction hose for water supply from

open containers (order no. 2.643-100.0)

31 Supplied screws and dowels

32 *Foam nozzle with detergent container: The deter-

gent is sucked out of the container to produce a

strong detergent foam.

33 *Rotating washing brush (e.g. for washing cars)

* optional, ** additionally required

Supplied screws and dowels

Illustration C

1 Stand dowels (2 pieces)

2 Screw M 4x20 (2 pieces)

3 Screw M 4x22 (2 pieces)

4 Screw M 4x16 (8 pieces)
