English 11

33 Wastewater container, removable

34 Wastewater container carrying handle

35 Cover seal

36 Fluff filter

Table of nozzle mouthpieces

Start-up

1. Check the power cord, extension cable and hoses

for damage before each start-up.

Installing accessories

1. Fit the suction pipe onto the floor nozzle and hand-

tighten the union nut on the floor nozzle.

2. If necessary, slide the D-handle onto the suction

pipe and hand-tighten in the desired position. The

D-handle is easier to slide on with the help of dish-

washing detergent or other lubricant.

3. Fit the handle onto the suction pipe and hand-tight-

en the union nut on the handle.

4. Connect the suction hose to the suction hose con-

nection on the device. Insert the spray hose cou-

pling into the spray hose connection on the device

and latch into place.

5. Connect the suction hose to the handle. Connect

the spray hose coupling to the handle and latch into

place.

Mixing the cleaning solution

 DANGER

Danger from detergents

Risk of injury and damage

Observe all instructions that are included with the deter-

gents used.

Note

Warm water (maximum 50 °C) increases the cleaning

effect. Check the temperature resistance of the surface

to be cleaned.

Note

Use detergents sparingly to conserve the environment.

1. Mix fresh water and detergent in a clean container

(concentration as specified for the detergent). Dis-

solve the detergent in the water.

Filling the fresh water tank

1. Pour the cleaning solution into the fresh water tank.

The filling level must not exceed the "MAX" mark.

Defoaming agent

Note

Foam is generated in the wastewater container when

cleaning previously shampooed carpets. Foaming can

be prevented by adding defoaming agents.

1. Puzzi 10/1 only: Add defoaming agent (special ac-

cessory) to the wastewater container.

2. Puzzi 10/2 Adv only: Open the defoaming agent

container. Fill with defoaming agent (special acces-

sories).

Replacing the carpet adapter

1. Press the floor nozzle latch on one side.

2. Swing out and remove the carpet adapter.

3. Insert a new carpet adapter and engage the latch.

Operation

Working with accessories

Puzzi 10/2 Adv only:

Note

An additional power socket is provided for connecting

additional electrical devices.

 DANGER

Danger of electric shock

Risk of injury and damage.

The socket is only intended for the direct connection of

the PW 30/1 additional brush washer head to the Puzzi

10/2 Adv. Any other use of the socket is prohibited.

Switching on the device

1. Connect the mains plug.

2. Press the suction switch to switch on the suction tur-

bine.

3. Press the spray switch to switch on the spray pump.

Cleaning mode

ATTENTION

Danger from cleaning solution

Risk of damage

Before using the device, check the object to be cleaned

for colour fastness and water resistance in an inconspic-

uous place.

1. Press the lever on the handle to spray the cleaning

solution.

2. Run over the surface to be cleaned in overlapping

paths. Pull the nozzle backwards (do not push).

3. When interrupting work, the suction pipe (with floor

nozzle) can be placed in the carrying handle of the

device.

Switching off the device

1. Switch off the spray switch and the suction switch.

2. Pull out the mains plug.

Empty the wastewater container

1. Switch off the suction switch and the spray switch

when the wastewater container is full.

2. Remove the cover.

3. Remove the wastewater container from the device

and empty it.

Emptying the fresh water tank

1. Switch off the device.

2. Briefly operate the lever on the handle to relieve

pressure.

3. Disconnect the handle from the spray/suction hose.

4. Hang the suction hose in the fresh water tank.

Colour Part

number

Flow vol-

ume

Applica-

tion

Approved

for device

Yellow 6.415-

165.0

2.0 l/min Floor noz-

zle

Puzzi 10/2

Green 6.415-

105.0

0.7 l/min Floor noz-

zle

Puzzi 9/1 Bp

Brown 6.415-

166.0

1.0 l/min Floor noz-

zle

Puzzi 8/1,

Puzzi 10/1

Blue 6.415-

928.0

1.0 l/min Uphol-

stery noz-

zle

Puzzi 8/1,

Puzzi 10/1,

Puzzi 10/2,

Puzzi 30/4

Red 6.415-

097.0

0.55 l/min Uphol-

stery noz-

zle, short

Puzzi 8/1,

Puzzi 9/1 Bp
