Recording a video

Press the Photo/Video/Playback button (20) to switch to video mode. The icon in the upper

le corner of the screen will change in conrmation. Press the capture button (9) to start

recording and press it again to stop.

Playback

Press the Photo/Video/Playback button (20) to switch to playback mode. The icon in the

upper le corner of the screen will change in conrmation. Select the desired photo or

video clip with Up (17) and Down (19) buttons and press OK (18) to play it.

Deleting les

When browsing saved les, press the Setup button (16), select Delete… and press OK (18)

to conrm selection (you can choose to delete everything or just the selected le from the

displayed menu).

Protecting les

When browsing saved les, press the Setup button (16), select Protect and press OK (18)

to conrm selection (you can choose to protect everything or just the selected le from

the displayed menu).

Polarizing lter

You can use a polarizing lter to reduce light reection while observing objects with a

shiny surface like metal, crystals, etc. Rotate the polarizing wheel (5) by 90 degrees to

activate or deactivate the polarizing eect.

Mass storage on PC

Insert a microSD card in the slot. Connect the microscope to your PC with the USB cable

to download images from the card to your computer.

Preview on PC

Only works with the soware installed. Remove the microSD card from the slot. Connect

the microscope to your PC with the USB cable.

Connecting the microscope to a TV-set

Plug the AV cable into the microscope and connect it to your TV-set (refer to the User

Guide of your TV-set for additional information). Turn on the TV and select the correct

channel from the corresponding menu of the TV-set (refer to the User Guide of your TV-

set for additional information).

Display menu

Press Setup button (16) to open the main display menu. From this menu you can set

image and video resolution, the interface language, date and time, turn on the power

saving mode, set up the TV connection, format the SD card, reset settings and check

the hardware version. Also, this menu provides access to the Loop recording mode

and Date Stamp option.

Resolution

Select the image or video Resolution from the main menu and choose the required

resolution by pressing the Down button (19), then conrm by pressing the OK button (18).

Note: This model supports the following image resolutions: 12M, 10M, 8M, 5M, 3M; video

resolutions: 1080P, 720P.

Capture mode

In photo mode, press the Setup button (16) and choose the Capture mode to setup the

sequence capture. For example, you can set up the microscope to take a photo every

5 seconds.

Loop recording

In video mode, press the Setup button (16) and choose the Loop recording mode. You

can select the duration of the video clip or turn the Loop recording mode o. While the

Loop recording mode is on, each video clip of selected duration will be recorded over the

previous one.

Date Stamp

Select Date Stamp from the main menu and then select a target option.

Date and time

Select Date/Time from the main menu by the Down button (19) and set the current date

and time.

TV connection

Select TV Mode from the main menu and then select, between NTSC and PAL, the correct

mode compatible with your TV. Press the OK button (18) to conrm selection.

Power saving

Select Auto Power O from the main menu and set the idle time before the microscope

automatically shuts down. Press the OK button (18) to conrm selection.

Settings reset

Select Default Setting from the main menu to revert back to factory settings.

Language

Select Language from the main menu and choose one of the existing settings. Press the

OK button (18) to conrm selection.

MicroSD card formatting

Select Format SD from the main menu to format the installed memory card. All the

les on the card will be deleted aer card formatting. Normally card formatting is not

necessary, unless your card is not able to store the captured image.

PortableCapture soware

Insert the installation CD into your CD drive. Choose the folder according to the

operating system of your device. Double click the installation le to install the

application and follow the instructions on screen. The installation CD contains a copy of

the user manual, which you can nd in the User Manual folder. Connect the microscope

to your PC with a USB cable and run the PortableCapture application. A pop-up

message will warn you if the microscope is not connected to the PC.
