Radius Circle. Draw a straight line on the image. The application will automatically

calculate the radius, as well as circumference and area of the corresponding circle.

Diameter Circle. Draw a straight line on the image. The application will automatically

calculate the diameter, as well as circumference and area of the corresponding circle.

Three Points Angle. Press and hold the le mouse button to draw a line on the image.

Release the le mouse button and draw another line. The application will automatically

calculate value of the resulting angle.

Draw and text

PortableCapture allows you to add drawings and textboxes to your images. Open an

image in a preview window and click the Pencil icon on the toolbar. Select one of the tools

from the drop-down menu and draw something on the image. By clicking the TT icon on

the toolbar, you can edit font type and color to be used in textboxes.

Specications

The manufacturer reserves the right to make changes to the product range and

specications without prior notice.

System requirements

Operating system: Windows 7/8/10, Mac 10.14 and above

CPU: at least P2 1GHz or above, RAM: 512MB, Video card: 512MB

Interface: USB 2.0, CD drive, any monitor with AV input

Care and maintenance

Never, under any circumstances, look directly at the Sun, another bright source of light

or at a laser through this device, as this may cause PERMANENT RETINAL DAMAGE and

may lead to BLINDNESS. Take necessary precautions when using the device with children or

others who have not read or who do not fully understand these instructions. Aer unpacking

your microscope and before using it for the rst time check for integrity and durability of every

component and connection. Do not try to disassemble the device on your own for any reason.

For repairs and cleaning of any kind, please contact your local specialized service center.

Protect the device from sudden impact and excessive mechanical force. Do not apply excessive

pressure when adjusting focus. Do not overtighten the locking screws. Do not touch the

optical surfaces with your ngers. To clean the device exterior, use only special cleaning wipes

and special optics cleaning tools from Levenhuk. Do not use any corrosive or acetone-based

uids to clean the optics. Abrasive particles, such as sand, should not be wiped o lenses, but

instead blown o or brushed away with a so brush. Do not use the device for lengthy periods

of time, or leave it unattended in direct sunlight. Keep the device away from water and high

humidity. Be careful during your observations, always replace the dust cover aer you are

nished with observations to protect the device from dust and stains. If you are not using your

microscope for extended periods of time, store the objective lenses and eyepieces separately

from the microscope. Store the device in a dry, cool place away from hazardous acids and

other chemicals, away from heaters, open re and other sources of high temperatures. When

using the microscope, try not to use it near ammable materials or substances (benzene,

paper, cardboard, plastic, etc.), as the base may heat up during use, and might become a

re hazard. Always unplug the microscope from a power source before opening the base or

changing the illumination lamp. Regardless of the lamp type (halogen or incandescent), give it

some time to cool down before trying to change it, and always change it to a lamp of the same

type. Always use the power supply with the proper voltage, i.e. indicated in the specications of

your new microscope. Plugging the instrument into a dierent power outlet may damage the

electric circuitry of the microscope, burn out the lamp, or even cause a short circuit. Children

should use the device under adult supervision only. Seek medical advice immediately if a

small part or a battery is swallowed.

Battery safety instructions

Always purchase the correct size and grade of battery most suitable for the intended use.

Always replace the whole set of batteries at one time; taking care not to mix old and new

ones, or batteries of dierent types. Clean the battery contacts and also those of the device

prior to battery installation. Make sure the batteries are installed correctly with regard to

polarity (+ and −). Remove batteries from equipment that is not to be used for an extended

period of time. Remove used batteries promptly. Never short-circuit batteries as this may

lead to high temperatures, leakage, or explosion. Never heat batteries in order to revive

them. Do not disassemble batteries. Remember to switch o devices aer use. Keep

batteries out of the reach of children, to avoid risk of ingestion, suocation, or poisoning.

Utilize used batteries as prescribed by your countrys laws.

Levenhuk Warranty

Levenhuk products, except for their accessories, carry a 10-year warranty against

defects in materials and workmanship. All Levenhuk accessories are warranted to be

free of defects in materials and workmanship for six months from the purchase date. The

warranty entitles you to the free repair or replacement of the Levenhuk product in any

country where a Levenhuk oce is located if all the warranty conditions are met.

For further details, please visit: www.levenhuk.com/warranty

If warranty problems arise or if you need assistance in using your product, please contact

the local Levenhuk branch.

LCD display 5"

Optics material optical glass

Megapixels 5

Magnication 10—300x

Photo *.jpg

Video *.avi

Focusing manual, 5—70mm

Speed 30fps

Illumination 8-LED system with brightness adjustment

Body material plastic

Power source 5V DC-in via USB cable or

built-in Li-ion battery: 3.7V, 2500mAh

work time: 3 hours; charging time: 7 hours

Soware image and video processing soware with measurement

function

Soware language English, German, French, Spanish, Russian, Japanese,

Chinese, etc.

Ability to connect additional

equipment

support of microSD cards with capacity up to 32GB (not

included in the kit)

connect to PC via USB cable (included)

connect to TV via AV cable (included)

Operating temperature range −10… +65 °C / 14… 149 °F
