20 21

Routine Maintenance

Note:

The float ball in the used water tank is a movable part. Do not

apply too much force when cleaning it to avoid damaging it.

Used Water Tank

1. Remove the used water tank, open its cover and pour out the used water.

2. Rinse the used water tank with clean water, and use the provided

cleaning tool to clean the inner wall of the used water tank.

Main Brush

1. Press the brush guard clips inwards to remove the brush guard and

lift the brush out of the robot.

2. Pull out the brush covers at both ends of the brush as shown in the

figure. Use the provided cleaning tool to remove any hair tangled in the

brush. Reinstall the brush covers on both ends of the brush, and then

reinstall the brush. Press on the brush guard to lock it in place.

Routine Maintenance

Side Brush & Mop Pad Holder

Remove and clean the side brush and mop pad holder.

Omnidirectional Wheel

Note:

Use a tool such as a small screwdriver to separate the axle and tire of

the omnidirectional wheel. Do not use excessive force.

Rinse the omnidirectional wheel under the running water and put it

back after drying it completely.

Dust Box

1. Open the robot's cover and press the clip to remove the dust box.

2. Open the dust box cover and empty the dust box as shown in the diagram.
