EN EXTERIOR (see page 2)

① – ring light; ② – protective cover; ③ – lens; ④ – LED indicator; ⑤ – colour temperature

mode button; ⑥ – light switch button; ⑦ – microphones; ⑧ – tripod; ⑨ – USB Type-C

connector.

SPECIFICATIONS

Purpose: web camera for video calls, video broadcasting, audio and video recording on

devices* based on Windows XP/7/8/10, Android 5.0 and above, macOS 10.6 and above,

Linux 2.6.24 and above, Chrome OS 29.01547 and above, Ubuntu 10.04 and above.

Design features. 80×40×32 mm; ABS plastic. Built-in ring light Ø 132 mm, removable

protective cover with a magnetic fastening.

Functional features. Connection: USB Type-A/Type-C cable. Power: 5 V / 1 A DC input, up

to 5 W. Camera: 5 MP, 1/2.8" sensor, 92° diagonal viewing angle, 3x digital zoom; up to

60 fps, up to 1944p. Microphone: dual, omnidirectional, 30–8000 Hz. Ring light: 36 LEDs,

1700–14000 K, 180° tilt angle. Operating conditions: −10...+45 °C, RH up to 85 % (non-

condensing). Storage conditions: −25...+60 °C, RH up to 85 % (non-condensing).

Scope of supply: LRG-SC910 web camera with the ring light, tripod, USB cable

Type-A/Type-C (2 m), protective cover, quick start guide.

GUIDELINES FOR SAFE USE

Avoid damaging the lens. Connect the web camera to devices* only, the webcam should not

be powered from an electrical network. Do not expose to high temperatures (from heaters,

direct sunlight), high humidity, avoid dust, liquids. Clean only after disconnecting from the

power supply, with a dry cloth only, without the use of detergents or cleaning agents or

solvents. Do not disassemble or attempt to repair it yourself. In the event of a malfunction,

contact the service center.

WEB CAMERA USE

1. Installation. See figure B on page 2.

2. Connection. Connect the USB cable (see figure C on page 2). Turn on the device *. On

first connection, wait until the standard drivers are installed. The web camera is then available

for use in applications on your device*.

3. Button Functions. Light switch button: see Fig. D on page 3. Colour temperature mode

button: see figure E on page 3.

TROUBLESHOOTING

The web camera does not work in the application you are using. Make sure that the web

camera is selected as the image and sound source in the application and operating system

settings. Check that the USB cable works properly. Check if the connector to which the web

camera is connected works properly. Make sure that you are using the latest version of the

application.

Poor image quality during a video broadcast or video call. Check the internet connection

speed. Reduce the web camera resolution in the settings of the application you are using.

The ring light went wrong or works intermittently. Make sure that the USB port on the

device * matches the power specifications of the web camera (see above).

FURTHER INFORMATION

The information is subject to change without notice to users. For the up-to-date information and

detailed descriptions of the web camera, its connection and operation procedure, certificates, and

warranty conditions, see the full user manual at lorgar.eu/drivers-and-manuals. All trademarks

and brand names are the property of their respective owners.

Manufacturer: ASBISc Enterprises PLC, Iapetou, 1, Agios Athanasios, 4101 Limassol, Cyprus.

Made in China.

* Device – computer, laptop, interactive panel, smart TV, etc.
