3.5. Mod Wheel

• MIDI Channel: Selects the MIDI channel [p.12] on which the wheel transmits.

• Output: Selects whether the wheel transmits a continuous controller (CC)

message or a non-registered parameter number (NRPN).

When Output is set to CC, the following parameters are available:

• CC: Selects the continuous controller message sent by the wheel (CC 1 is the MIDI

standard for modulation).

• Min Value: Sets the value sent at the wheel’s minimum position.

• Max Value: Sets the value sent at the wheel’s maximum position.

When Output is set to NRPN, the available parameters change.

• Parameter MSB: Adjusts the most significant bit in the NRPN.

• Parameter LSB: Adjusts the least significant bit in the NRPN.



♪ What is this NRPN, MSB, and LSB stuff? We don’t have room for a full MIDI tutorial but in a

nutshell, a non-registered parameter is a way of sending instrument-specific or manufacturer-specific

commands that go beyond the core MIDI standard. Unlike a CC, an NRPN sends two values: the most

and least significant bits. This allows for 16,384 possible values instead of just 127.

Arturia - User Manual MIDI Control Center for KeyLab Essential mk3 - Editing a Template 14
