3.11.2. With Knob Output set to NRPN

• Output: Selects whether the knob transmits a continuous controller (CC) message

or a non-registered parameter number (NRPN). In NRPN mode, the following

settings are available:

• MIDI Channel: Selects the MIDI channel [p.12] on which the encoder knob

transmits.

• Scale: Adjusts how finely or coarsely the knob moves through the range of values

when turned.

• Parameter MSB: Adjusts the most significant bit in the NRPN.

• Parameter LSB: Adjusts the least significant bit in the NRPN.



♪ You can invert the knob’s behavior (clockwise = down and counterclockwise = up) by making the

minimum value greater than the maximum.

3.12. Faders 1–9

The faders are relatively simple — they send MIDI CC messages only.

• MIDI Channel: Selects the MIDI channel [p.12] on which the fader transmits.

• CC: Selects the continuous controller message sent by the fader.

• Fader Mode:

◦

Fader

: Moving the fader upwards increases the value; downwards

decreases it.

◦

Drawbar

: Moving the fader downwards

increases

the value; upwards

decreases it, like on a drawbar organ.

• Min Value: Sets the lower value limit.

• Max Value: Sets the upper value limit.



♪ Drawbar mode does the same thing as swapping the maximum and minimum values, only with

one click. This makes the fader work like an organ drawbar in instruments such as Arturia B-3 V.

25 Arturia - User Manual MIDI Control Center for KeyLab Essential mk3 - Editing a Template
