14 | English
u Secure the workpiece. A workpiece clamped with
clamping devices or in a vice is held more secure than by
hand.
u Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility com-
pany for assistance. Contact with electric lines can lead
to fire and electric shock. Damaging a gas line can lead to
explosion. Penetrating a water line causes property dam-
age or may cause an electric shock.
u Always wait until the power tool has come to a com-
plete stop before placing it down. The application tool
can jam and cause you to lose control of the power tool.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The power tool is intended for hammer drilling in concrete,
brick and stone, as well as for light chiselling work. It is also
suitable for drilling without impact in wood, metal, ceramic
and plastic. Power tools with electronic control and right/left
rotation are also suitable for screwdriving.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Keyless chuck
A)
(2)
SDS-plus drill chuck
(3)
SDS-plus tool holder
(4)
Dust protection cap
(5)
Locking sleeve
(6)
Lock-on button for on/off switch
(7)
On/off switch
(8)
Rotational direction switch
(9)
Release button for impact/mode selector switch
(10)
Impact/mode selector switch
(11)
Button for depth stop adjustment
(12)
Auxiliary handle (insulated gripping surface)
(13)
Depth stop
(14)
Handle (insulated gripping surface)
(15)
Securing screw for keyed chuck
A)
(16)
Keyed chuck
A)
(17)
SDS-plus shank for drill chuck
A)
(18)
Front sleeve of the keyless chuck
(19)
Rear sleeve of the keyless chuck
(20)
Saugfix suction opening
A)
(21)
Saugfix clamping screw
A)
(22)
Saugfix depth stop
A)
(23)
Saugfix telescopic tube
A)
(24)
Saugfix wing bolt
A)
(25)
Saugfix guide tube
A)
(26)
Universal holder with SDS-plus shank
A)
A)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Rotary hammer GBH 220
Article number
3611BA60..
Rated power input W 720
Impact rate min
-1
0-4800
Impact energy per stroke ac-
cording to EPTA-Proced-
ure05:2016
J 2.0
No-load speed min
-1
0–2000
Tool holder SDS-plus
Spindle collar diameter mm 48.5
Max. drilling diameter
– Concrete
A)
mm 22
– Steel mm 13
– Wood mm 30
Weight according to EPTA-
Procedure 01:2014
kg 2.3
Protection class
/ II
A)
optimum performance with drilling diameter 6−12mm
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Noise/Vibration Information
Noise emission values determined according
toEN60745-2-6.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level94dB(A); sound power
level105dB(A). Uncertainty K=3dB.
Wear hearing protection!
1 609 92A 5PD | (20.08.2020) Bosch Power Tools
