9 ENGLISH

NOTE:Whenalllampsontheswitchpanelgoout,thetoolisturnedofftosavethebatterypower.Theimpactforce

grade can be checked by pulling the switch trigger to the extent that the tool does not operate.

NOTE:Whilepullingtheswitchtrigger,theimpactforcegradecannotbechanged.

ASSEMBLY

CAUTION: Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing driver bit/

socket bit

►Fig.9

Useonlydriverbit/socketbitthathasinsertingportion

showninthegure.Donotuseanyotherdriverbit/

socket bit.

For tool with shallow driver bit hole

A=12mm

B=9mm

Use only these type of driver

bit. Follow the procedure

1. (Note) Bit-piece is not

necessary.

For tool with deep driver bit hole

A=17mm

B=14mm

To install these types of driver

bits, follow the procedure 1.

A=12mm

B=9mm

To install these types of driver

bits, follow the procedure 2.

(Note) Bit-piece is necessary

for installing the bit.

Procedure 1

For tool without one-touch type sleeve

►Fig.10: 1. Driver bit 2. Sleeve

To install the driver bit, pull the sleeve in the direction of

the arrow and insert the driver bit into the sleeve as far

as it will go.

Then release the sleeve to secure the driver bit.

For tool with one-touch type sleeve

To install the driver bit, insert the driver bit into the

sleeve as far as it will go.

Procedure 2

In addition to Procedure 1, insert the bit-piece into the

sleeve with its pointed end facing in.

►Fig.11: 1. Driver bit 2. Bit-piece 3. Sleeve

To remove the driver bit, pull the sleeve in the direction

of the arrow and pull the driver bit out.

NOTE: If the driver bit is not inserted deep enough

into the sleeve, the sleeve will not return to its original

position and the driver bit will not be secured. In this

case, try re-inserting the bit according to the instruc-

tions above.

NOTE:Whenitisdifculttoinsertthedriverbit,pull

the sleeve and insert it into the sleeve as far as it will

go.

NOTE:Afterinsertingthedriverbit,makesurethatit

isrmlysecured.Ifitcomesout,donotuseit.

Installing hook

►Fig.12: 1. Groove 2. Hook 3. Screw

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool. To install

the hook, insert it into a groove in the tool housing on

either side and then secure it with a screw. To remove,

loosen the screw and then take it out.

OPERATION

►Fig.13

The proper fastening torque may differ depending upon

thekindorsizeofthescrew/bolt,thematerialofthe

workpiece to be fastened, etc. The relation between fas-

teningtorqueandfasteningtimeisshowninthegures.

Proper fastening torque for standard bolt

►Fig.14: 1. Fastening time (second) 2. Fastening

torque

Proper fastening torque for high tensile bolt

►Fig.15: 1. Fastening time (second) 2. Fastening

torque

Holdthetoolrmlyandplacethepointofthedriverbit

inthescrewhead.Applyforwardpressuretothetoolto

the extent that the bit will not slip off the screw and turn

the tool on to start operation.

NOTICE: If you use a spare battery to continue

the operation, rest the tool at least 15 min.

NOTE:Usetheproperbitfortheheadofthescrew/

bolt that you wish to use.

NOTE:WhenfasteningM8orsmallerscrew,carefully

adjustpressureontheswitchtriggersothatthescrew

is not damaged.

NOTE: Hold the tool pointed straight at the screw.

NOTE: If the impact force is too strong or you tighten

thescrewforatimelongerthanshowninthegures,

the screw or the point of the driver bit may be over-

stressed, stripped, damaged, etc. Before starting your

job,alwaysperformatestoperationtodeterminethe

proper fastening time for your screw.
