󱂅 Specifications

(Depending on country)

Broadcasting Specifications

Digital TV Analogue TV

Television system

DVB-S/S2

DVB-C

DVB-T/T2

PAL B/B, B/G, D/K, I,

SECAM B/G, D/K, L

Channel coverage

(Band)

DVB-S/S2 DVB-C DVB-T/T2

46 ~ 862 MHz

950 ~ 2,150 MHz 46 ~ 890MHz

VHF III : 174 ~ 230 MHz

UHF IV : 470 ~ 606 MHz

UHF V : 606 ~ 862 MHz

S Band II : 230 ~ 300 MHz

S Band III : 300 ~ 470 MHz

Maximum number of

storable programmes

6,000 3,000

External antenna

impedance

75Ω

CI Module (W x H x D) 100.0mm x 55.0mm x 5.0mm

Wireless module (LGSBWAC92) specifications

Wireless LAN (IEEE 802.11a/b/g/n/ac)

Frequency range Output Power (Max.)

2,400 to 2,483.5MHz 18dBm

5,150 to 5,725MHz 18dBm

5,725 to 5,850MHz (Not for EU) 12dBm

Bluetooth

Frequency range Output Power (Max.)

2,400 to 2,483.5MHz 8dBm

As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional

frequency table.

For consideration of the user, this device should be installed and operated with a minimum distance of 20 cm between the device and the body.

* IEEE 802.11ac is not available in all countries.

Environment condition

Operating Temperature 0°C to 40°C

Operating Humidity Less than 80%

Storage Temperature -20°C to 60°C

Storage Humidity Less than 85%

• For information of the power supply and power consumption, refer to the label attached to the product.

- The typical power consumption is measured in accordance with IEC 62087 or each country’s energy regulations.

* On some models, the label is inside the external device connection terminal cover.

* Depending on the model or country, the typical power consumption may not be on label.
