English

Connecting to a DJ mixer

Analog player DJ mixer

Ground wire Ground wire

Audio cable

Audio

cable

Rear panel

Power cord

To power outlet

1 Connect the audio cable and ground wire to the [PHONO] input terminal of the DJ mixer.

 If this product is connected to a DJ mixer that does not have a [PHONO] input terminal, sufficient volume and sound quality cannot be

obtained.

 Make sure to connect the ground wire. If the unit is not properly grounded, a power hum (humming sound) occurs.

2 Connect the power cord.

Connects to a power outlet using the included power cord. Wait until all connections between the equipment are completed before connecting the

power cord.

 Before connecting to the outlet (AC outlet) mounted on the connected equipment, check the wattage displayed on the outlet. (This unit con-

sumes 9 W of power.)

Place of installation

Place the unit on a level surface that is free of external vibration.

 To the extent possible, keep the unit away from the speaker system.



When the unit is very close to a radio (AM/FM broadcasting), the radio could generate noise. Keep the distance as far away from the unit as possible.

Adjusting the height of the main unit

Adjust the height by turning the insulator in a way that the main unit is horizontal.
