English

i HEIGHT ADJUST lock

Locks the adjusted height of the arm.

 Adjusting the arm height (p. 9 )

j HEIGHT ADJUST dial

Used to adjust the height of the tone arm.

 Adjusting the arm height (p. 9 )

k Balance weight

Used to balance the tone arm and adjust the stylus pressure.

 Adjustment (p. 8 )

l Stylus pressure adjustment ring

Used to match to the appropriate stylus pressure of the cartridge.

 Adjusting the stylus pressure (p. 8 )

m Headshell stand

Used to stand the shell up.

n Adapter for EP record

Used to play standard EP records.

 To play a standard EP record (p. 12 )

Rear panel

For the terminals used for connections, see Descriptions of terminals

on page 10 .

1 Kensington security slot

2 Insulator

Suppresses the effect of outside vibration. Turning the insulator

adjusts the turntable height.

 Adjusting the height of the main unit (p. 11 )
