En
9
English
Adjusting the arm lifter height
If necessary, perform adjustment to match the cartridge being used.
Prepare as follows.
Place a record on the turntable sheet.
Remove the stylus cover and arm clamper while paying attention not
to touch the stylus tip.
Pull up the lifter lever and move the tone arm onto the record.
Adjust the height by turning the screw while the arm
lifter is pushed down.
Turing clockwise narrows the distance between the record and
stylus.
Turing counterclockwise widens the distance between the record
and stylus.
The arm lifter height (the distance between the record and stylus when
the lifter lever is pulled up) is factory-adjusted in a range between
approximately 8 mm and 13 mm.
Arm lifter
Screw
Adjusting the arm height
1 Turn the [HEIGHT ADJUST] lock to unlock the lock.
Unlock
2 Push down the lifter lever and place the stylus on the
record, then adjust the [HEIGHT ADJUST] dial to make
the tone arm and record parallel.
Adjust so that the tone arm becomes horizontal
[HEIGHTADJUST]dial
Refer to the following table to adjust the [HEIGHT ADJUST] dial to match
the height to your cartridge size.
H
Cartridge size H
(mm)
[HEIGHT ADJUST]
dial
scale position
19 0
20 1
21 2
22 3
23 4
24 5
25 6
3 Turn the [HEIGHT ADJUST] lock to fix the height of
the arm.
After adjusting height of the arm, always turn the [HEIGHT ADJUST]
lock to fix the arm.
When scratch play is performed
To prevent stylus jumping, use the [HEIGHT ADJUST] dial to adjust the
arm height to match the play action.
