– 7
The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service center.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
Subject to technical changes.
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements of the EU Directives, both in its basic design
and construction as well as in the version put into circu-
lation by us. This declaration shall cease to be valid if
the machine is modified without our prior approval.
The signatories act on behalf of and with the authority of
the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Straße 28-40
71364 Winnenden (Germany)
Tel.: +49 7195 14-0
Fax: +49 7195 14-2212
Warranty
Technical specifications
Electrical connection
Voltage 220-240
1~50-60
V
Hz
Power consumption 6 A
Protection class IPX5
Protective class II
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 7 I/min
Performance data
Working pressure 7,4 MPa
Max. permissible pressure 11 MPa
Water flow rate 5,5 I/min
Max. flow rate 6,0 I/min
Recoil force of trigger gun 11 N
Dimensions and weights
Length 278 mm
Width 233 mm
Height 296 mm
Weight, ready to operate with acces-
sories
4,7 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
0,7
0,6
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
77
2
dB(A)
dB(A)
Sound power level L
WA
+ Uncertainty
K
WA
91 dB(A)
EU Declaration of Conformity
Product: High pressure cleaner
Type: 1.600-xxx
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2014/30/EU
2011/65/EU
2000/14/EC
Applied harmonized standards
EN 60335–1
EN 60335–2–79
EN 62233: 2008
EN 55014–1: 2017
EN 55014–2: 2015
EN 61000–3–2: 2014
EN 61000–3–3: 2013
EN 50581
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 89
Guaranteed: 91
Winnenden, 2020/08/01
Chairman of the Board of Management
Director Regulatory Affairs & Certification
11EN
