INSTALLATION INSTRUCTIONS, MAINTENANCE

AND USING THE DISPOSER

Before installing the product, read everything care-

fully. Installation, maintenance and use manual. Be-

fore starting work determine which tools, materials,

and equipment you need.

Before installing the disposer, make sure that you

have all the necessary parts of the product.

REQUIRED TOOLS AND MATERIALS:

screwdriver, Hinged pliers, insulation tape, protece-

tive glasses

REQUIRED INSTRUMENTS, MATERIALS AND

OPTIONAL EQUIPMENT:

a Phillips screwdriver, a drainage drill, electrical

terminal 9.5 mm, threaded nuts (2), siphon 38 mm,

drill 25 mm, hammer, hacksaw, water hose clamp,

pipe pliers, copper grounding wire, dishwasher

drainage pipe kit, electric switch, extension pipe

1. DESCRIPTION OF THE PRODUCT (FIG.1.1)

Assembly unit

1. Stopper

2. Washing ange

3. Rubber gaskets (2)

4. Support ring

5. Mounting ring

6. Screws

7. Locking ring

8. Sound attenuating screen Disposer

9. Installation gasket / protective reector

10. Eyelets

11. Lower mounting ring

12. Drain the dishwasher

13. Outlet opening Drainage system

14. Mounting Screws

15. Rubber gasket

16. Flange

17. Drain pipe with a knee

2. DISCONNECTION OF THE DROP HORN AT-

TENTION!

At the time of installation of the device is

recommended Wear safety glasses. Loosen the

nut (1) on the top of the water trap (4) with a pipe

wrench (Fig. 3.1). relative humidity not more than

80%. Loosen the nut (2) on the top of the extension

pipe. Remove the extension pipe.

Loosen the nut (3) at the bottom of the washing

ange.

Push the washing ange upwards through drain

hole of the sink and remove it (Fig. 3.2).

CLEAN THE WASH FAN WRAPPING PLACE FROM THE

SEALANT OR THE GARBAGE.

English

oder reparieren Sie das Produkt, wenden Sie sich an

einen autorisierten Händler Service Center oder zu

Ihrem Händler.

Die Garantie erlischt in folgenden Fällen:

- wenn das Produkt mit Beeinträchtigungen ver-

wendet wurde Anforderungen dieses Handbuchs

- in Gegenwart von Spuren der Önung des Körpers

des Produkts zur Selbstreparatur

Weitere Informationen zu den Garantiebedingun-

gen nden Sie in der Garantie Coupon.
