• Threading the Lower Looper

Open the looper cover and side cover.

Place the spool of thread on the right side spool pin.

The points to thread for lower looper are marked

in green.

A convenient threading chart is placed on the

machine body inside the looper cover.

1. Draw the thread through the right side thread

guide from back to front: (A)

If the thread is coming out from the thread guide

groove, pass the thread through the thread guide

hole again as shown: (B)

Thread guide

2. Pass the thread through the holes on the right side

of the thread guide plate as illustrated.

Thread guide plate

(A) (B)

124 3

• Çàïðàâêà íèæíåãî ïåòëèòåëÿ

Îòêðîéòå áîêîâóþ êðûøêó è êðûøêó ïåòëèòåëåé.

Óñòàíîâèòå êàòóøêó íà ïðàâûé êàòóøå÷íûé

ñòåðæåíü.

* Äîðîæêà çàïðàâêè íèòè íèæíåãî ïåòëèòåëÿ

îòìå÷åíà çåëåíûì öâåòîì.

* Óäîáíàÿ ñõåìà çàïðàâêè îáîçíà÷åíà íà

êðûøêå ïåòëèòåëÿ âíóòðè ìàøèíû.

1. Ïðîâåäèòå íèòü ÷åðåç ïðàâûé íàïðàâèòåëü

àíòåííû ñçàäè íàïåðåä: (À).

* Åñëè íèòü âûñêî÷èëà èç íàïðàâèòåëÿ àíòåííû,

ïðîïóñòèòå åå ñíîâà ÷åðåç îòâåðñòèå

íàïðàâèòåëÿ êàê ïîêàçàíî íà ðèñóíêå: (Â).

1 Íàïðàâèòåëü àíòåííû

2. Ïðîïóñòèòå íèòü ñêâîçü îòâåðñòèÿ

íèòåíàïðàâèòåëüíîé ïëàñòèíû ñ ïðàâîé

ñòîðîíû êàê ïîêàçàíî íà ðèñóíêå.

2 Íèòåíàïðàâèòåëüíàÿ ïëàñòèíà
