WIRELESS SETUP

Configure Bamboo for wireless operation.

1. If you have been using Bamboo as a wired tablet, disconnect the USB cable.

2. Turn the tablet over. Remove the wireless compartment cover(s). See (A).

Slide cover(s) away from tablet body to remove. Tablet model CTH-670 is

equipped with two covers: one for the Wacom wireless module, and one for

the rechargeable battery.

3. Install the wireless components.

4. If you have not already done so, turn on your computer and wait until the system has fully loaded.

Next, connect wirelessly.

Establishing a wireless connection

Optimizing the wireless connection

• Install the battery. Align contacts (B) as

shown and press into place. See also

replacing the battery

• Install the wireless module. Lift away and

remove the wireless module spacer (C). Slide

the wireless module into the tablet, ensuring

the connector is fully seated (D).

Important: Save the module spacer. You

may need it as a tool for removal of the

wireless module, and to protect the tablet

interior from dust when the module is not

installed. See wireless module removal

• Replace the wireless compartment cover(s).

Align and slide into place (E).

• Connect the Wacom wireless receiver to an

active USB port on your computer or USB

hub (F).

When not in use, store the receiver in the

wireless receiver storage compartment.

See wireless receiver storage
