TESTING A PEN

1. First perform the procedures for testing your tablet.

2. Check the pen by opening the Bamboo control panel and selecting the P

EN tab. Click on the DEFAULT

button to return the pen to its default settings. Next:

• Touch the pen tip and then the eraser (when equipped) to the tablet active area. Each time the tip or

eraser makes contact with the tablet surface, the status LED should provide a visual indication.

Models CTH-470 and CTH-670

: the LED should glow white.

Model CTL-470

: the LED should brighten.

• Without applying pressure to the pen tip, hold the pen tip within approximately 7 mm (0.28 inch) of

the tablet surface and press each pen button in turn. For each button press, the status LED should

provide a visual indication.

Models CTH-470 and CTH-670

: The LED should glow white.

Model CTL-470

: The LED should brighten.

• While still within proximity, but without touching the tablet surface, move your pen across the active

area of the tablet. The screen cursor should move in the corresponding direction on your monitor or

display screen.

3. If any of these tests fail you may have defective hardware. See technical support options

4. After testing, use the Bamboo control panel to reconfigure your tablet and pen for any custom settings

you may originally have been using.
