9Getting to know your smartphone

LED indicators

Call indicator:

Mail/message indicator:

7 Phone speaker Emits audio from your smartphone; suitable for holding

to your ear.

8 IR LED Works in conjunction with the proximity sensor.

9 Proximity and light sensor Dims the display and deactivates the touchscreen when

the devie is brought near the face during a call. Adjusts

the display brightness depending on lighting conditions.

10 Home button Returns to the Home screen; press and hold to view

recently-used applications, tap an icon to open the

associated program.

11 Search button Opens the Google search function.

12 Back button Goes back one menu step; closes the keyboard.

13 Menu button Opens the option menu; press and hold to display the

keyboard.

14 Volume up/down button Increases or decreases the phone volume.

15 Camera button Activates the camera or takes a picture. Press down

halfway to auto-focus.

16 Camera A 5-megapixel camera for taking high-resolution images.

17 Flash Produces light for picture taking and video recording.

18 Second microphone Internal microphone

19 Handsfree speaker Emits audio from your smartphone; suitable for

handsfree use.

20 Micro USB connector Connects to a USB cable/charger.

21 Microphone Internal microphone.

LED state Description

Off No incoming or missed calls.

Fast flashing Incoming call.

Slow flashing Missed call(s).

LED state Description

Off No unread mail or messages.

Slow flashing Unread mail or messages.

No. Item Description
