English

H Adjust the vertical slide

Adjust the vertical slide with the two M8 x 35 mm hexagon socket head cap bolts at the bottom of the

mounting bracket. Tightening the bolts raises the mounting bracket, and loosening them lowers it.

The projection screen is raised or lowered accordingly.

I Adjust the forward/backward slide

Loosen the four screws and adjust the slider of the mounting bracket.

After you finish making all of the adjustments in steps

E to I, tighten the screws.

J Turn off the display of the test pattern

Press the [Esc] button on the remote control or control panel to turn off the test pattern.

M8 x 35 mm

hexagon socket

head cap bolts (2)

Screws (4)

Tighten all screws firmly. If the screws are not tightened firmly, the projector or mounting

bracket may fall and cause personal injury or property damage.

Warning
