8
Component
Location
Description
Electric Generator
Engine
Compartment
MG1, which is driven by the engine, generates high-
voltage electricity in order to operate MG2, MGR*1 and
charge the HV battery. Also, it functions as a starter to
start the engine.
A/C Compressor
(with Inverter)
Engine
Compartment
3-phase high voltage AC electrically driven motor
compressor.
DC-DC Converter
for 12 Volt
Auxiliary Battery
Engine
Compartment
Steps down the HV battery nominal voltage of DC 201.6
V*2 / DC 207.2 V*3 / DC 222.0 V*4 to approximately
DC 14 V in order to supply electricity to the electrical
components, as well as to recharge the auxiliary battery.
Fuel Tank and Fuel
Line
Undercarriage and
Center
The fuel tank provides gasoline via a fuel line to the
engine. The fuel line is routed under the center of
vehicle.
Rear Electric
Motor *1
Under the Luggage
Compartment
MGR, which is driven by electrical power from MG1 and
the HV battery, generates motive force for the drive
wheels.
*Numbers in the component column apply to the illustrations on the following page.
*1: for AWD Models
*2: for Nickel-Metal hydride battery
*3: for Lithium-ion battery (2ZR-FXE)
*4: for Lithium-ion battery (M20A-FXS)
