19
Service Plug Grip
• The high-voltage circuit is cut by removing the service plug grip (see page 25).
for 2ZR-FXE or 2ZR-FXB
High Voltage Safety System – Vehicle Shut Off (READY-OFF)
High Voltage Safety System – Vehicle On and Operational (READY-ON)
*1: for Nickel-Metal hydride battery
*2: for Lithium-ion battery (2ZR-FXE)
HV Battery Pack
Hybrid Vehicle Computer
Volts DC
A/C
Compressor
Electric
Generator
600 Volts AC
Max 3-Phase
Inverter/
Converter
Volts DC
12 Volts
Auxiliary
Battery
Electric
Motor
HV Battery Pack
Hybrid Vehicle Computer
A/C
Compressor
Electric
Generator
Electric
Motor
0 Volts AC
3-Phase
Inverter/
Converter
12 Volts
Auxiliary
Battery
Volts DC
0.0
0.0
Volts DC
