Specifications

CPU

∙ Supports 12th/ 13th Gen Intel® Core™ Processors,

Pentium® Gold and Celeron® Processors*

∙ Processor socket LGA1700

* Please go to www.msi.com to get the newest support status as new processors

are released.

Chipset Intel® B760 Chipset

Memory

∙ 2x DDR4 memory slots, supporting up to 64GB*

∙ Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)

• 1DPC 1R Max speed up to 4800+ MHz

• 1DPC 2R Max speed up to 4600+ MHz

∙ Supports Dual-Channel mode

∙ Supports non-ECC, un-buffered memory

∙ Supports Intel® Extreme Memory Profile (XMP)

* Please refer to www.msi.com for more information on compatible memory.

Expansion Slots

∙ 1x PCIe 4.0 x16 slot (From CPU)

∙ 1x PCIe 4.0 x1 slot (From B760 Chipset)

Onboard Graphics

∙ 1x HDMI™ 2.1 port with HDR, supporting a maximum

resolution of 4K 60Hz*/**

* Available for the processor with integrated graphics.

** Graphics specifications may vary depending on the CPU installed.

SATA Ports 4x SATA 6Gb/s ports (From B760 chipset)

M.2 SSD Slot

∙ 1x M.2 slot (Key M)

• M2_1 slot (From CPU)

• Supports up to PCIe 4.0 x4

• Supports 2242/ 2260/ 2280 storage devices

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA

storage devices

Audio

Realtek® ALC897Codec

∙ 7.1-Channel High Definition Audio

LAN 1x Realtek® RTL8125B 2.5Gbps LAN controller

Power Connectors

∙ 1x 24-pin ATX main power connector

∙ 1x 8-pin +12V power connector

Continued on next column
