Specifications

CPU

∙ Supports Intel® Core™ 14th/ 13th/ 12th Gen Processors,

Intel® Pentium® Gold and Celeron® Processors*

∙ Processor socket LGA1700

* Please go to www.msi.com to get the newest support status as new processors

are released.

Chipset Intel® B760 Chipset

Memory

∙ 4x DDR4 memory slots, supporting up to 128GB*

∙ Supports 1R 2133/2666/3200 MHz (by JEDEC & POR)

∙ Max overclocking frequency:

• 1DPC 1R Max speed up to 5333+ MHz

• 1DPC 2R Max speed up to 4800+ MHz

• 2DPC 1R Max speed up to 4400+ MHz

• 2DPC 2R Max speed up to 4000+ MHz

∙ Supports Dual-Channel mode

∙ Supports non-ECC, un-buffered memory

∙ Supports Intel® Extreme Memory Profile (XMP)

* Please refer to www.msi.com for more information on compatible memory.

Expansion Slots

∙ 2x PCIe x16 slots

• PCI_E1 slot (From CPU)

• Supports PCIe 5.0 x16

• PCI_E2 slot (From B760 Chipset)

• Supports PCIe 3.0 x4

∙ 1x PCIe x1 slot

• PCIE_E3 slot (From B760 Chipset)

• Supports PCIe 4.0 x1

Onboard Graphics

∙ 1x HDMI™ 2.1 port with HDR, supporting a maximum

resolution of 4K 60Hz*/ **

∙ 1x DisplayPort 1.4 port with HBR3, supporting a maximum

resolution of 8K 60Hz*/ **

* Available only on processors featuring integrated graphics.

** Graphics specifications may vary depending on the CPU installed.

SATA Ports

4x SATA 6Gb/s ports* (From B760 chipset)

* SATA7 will be unavailable when installing M2.SATA SSD in the M2_3 slot.

Continued on next column
