Continued from previous column

Internal USB

Connectors

∙ 1x USB 3.2 Gen 2 10Gbps Type-C front panel connector

(From B760 chipset)

∙ 1x USB 3.2 Gen 1 5Gbps connector (From B760 chipset)

• Support additional 2 USB 3.2 Gen 1 5Gbps ports

∙ 2x USB 2.0 Type-A connectors (From B760 chipset)

• Supports additional 4 USB 2.0 ports

Fan Connectors

∙ 1x 4-pin CPU fan connector

∙ 1x 4-pin water-pump fan connector

∙ 5x 4-pin system fan connectors

System Connectors

∙ 1x Front panel audio connector

∙ 2x System panel connectors

∙ 1x Chassis intrusion connector

∙ 1x TPM module connector

∙ 1x Tuning controller connector

∙ 1x TBT connector (Supports RTD3)

Jumpers ∙ 1x Clear CMOS jumper

LED Features

∙ 2x 4-pin RGB LED connectors

∙ 2x 3-pin ARGB Gen2 LED connectors

∙ 4x EZ Debug LED

Back Panel

Connectors

∙ 4x USB 2.0 Type-A ports (From Hub GL850G)

∙ 1x DisplayPort port

∙ 1x HDMI™ port

∙ 1x 2.5Gbps LAN (RJ45) port

∙ 4x USB 3.2 Gen 2 10Gbps Type-A ports (From GL3590 Hub)

∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port (From B760

chipset)

∙ 2x Wi-Fi antenna connectors

∙ 5x Audio jacks

∙ 1x Optical S/PDIF Out connector

I/O Controller NUVOTON NCT6687 Controller Chip
