Specifications

CPU

∙ Supports Intel® Core™ 14th/ 13th/ 12th Gen Processors,

Intel® Pentium® Gold and Celeron® Processors*

∙ Processor socket LGA1700

* Please go to www.msi.com to get the newest support status as new processors

are released.

Chipset Intel® B760 Chipset

Memory

∙ 4x DDR4 memory slots, supporting up to 128GB*

∙ Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)

∙ Max overclocking frequency:

• 1DPC 1R Max speed up to 4800+ MHz

• 1DPC 2R Max speed up to 4600+ MHz

• 2DPC 1R Max speed up to 4400+ MHz

• 2DPC 2R Max speed up to 4000+ MHz

∙ Supports Dual-Channel mode

∙ Supports non-ECC, un-buffered memory

∙ Supports Intel® Extreme Memory Profile (XMP)

* Please refer to www.msi.com for more information on compatible memory.

Expansion Slots

∙ 1x PCIe x16 slot

• PCI_E1 slot (From CPU)

• Supports PCIe 4.0 x16

∙ 2x PCIe x1 slots

• PCI_E2 & PCI_E3 slots (From B760 chipset)

• Support PCIe 4.0 x1

Onboard Graphics

∙ 1x HDMI™ 1.4 port, supporting a maximum resolution of

4K 30Hz*/**

∙ 1x DisplayPort 1.4 port, supporting a maximum resolution

of 4K 60Hz*/**

∙ 1x VGA port, supporting a maximum resolution of

2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*/**

* Available only on processors featuring integrated graphics.

** Graphics specifications may vary depending on the CPU installed.

SATA Ports

4x SATA 6Gb/s ports* (From B760 chipset)

* SATA5 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.

Continued on next column
