Specifications

CPU

∙ Supports 12th Gen Intel® Core™ Processors

∙ Processor socket LGA1700

* Please go to www.msi.com to get the newest support status as new processors

are released.

Chipset Intel® Z690 Chipset

Memory

∙ 4x DDR5 memory slots, support up to 192GB*

∙ Supports 1R 4800 MHz (by JEDEC & POR)

• 1DPC 1R Max speed up to 6200+ MHz

• 1DPC 2R Max speed up to 5200+ MHz

• 2DPC 1R Max speed up to 4000+ MHz

• 2DPC 2R Max speed up to 4000+ MHz

∙ Supports Intel® XMP 3.0 OC

∙ Supports Dual Controller Dual-Channel mode

∙ Supports non-ECC, un-buffered memory

* Please refer to www.msi.com for more information on compatible memory.

Expansion Slots

∙ 4x PCIe x16 slots

• PCI_E1 (From CPU)

• Support up to PCIe 5.0 x16

• PCI_E2 & PCI_E3 (From Z690 chipset)

• Support up to PCIe 3.0 x1

• PCI_E4 (From Z690 chipset)

• Support up to PCIe 3.0 x4

∙ 2x PCIe x1 slots

• PCI_E5 & PCI_E6 (From Z690 chipset)

• Support up to PCIe 3.0 x1

Multi-GPU ∙ Supports AMD CrossFire™ Technology

Onboard Graphics

∙ 1x HDMI™ 1.4 with HDR port, supporting a maximum

resolution of 4K 30Hz*/**

∙ 1x DisplayPort 1.4 port, supporting a maximum resolution

of 4K 60Hz*/**

* Available only on processors featuring integrated graphics.

** Graphics specifications may vary depending on the CPU installed.

SATA Ports ∙ 4x SATA 6Gb/s ports (From Z690 chipset)

Continued on next page
