Continued from previous page

Fan Connectors

∙ 1x 4-pin CPU fan connector

∙ 1x 4-pin water-pump fan connector

∙ 4x 4-pin system fan connectors

System Connectors

∙ 1x Front panel audio connector

∙ 2x System panel connectors

∙ 1x Chassis Intrusion connector

∙ 1x TPM module connector

∙ 1x Tuning controller connector

∙ 1x TBT connector (Supports RTD3)

Jumpers ∙ 1x Clear CMOS jumper

LED Features

∙ 1x 4-pin RGB LED connector

∙ 1x 3-pin RAINBOW LED connector

∙ 4x EZ Debug LED

Back Panel

Connectors

∙ 1x PS/2 keyboard/ mouse combo port

∙ 2x USB 2.0 Type-A ports (From Z690 chipset)

∙ 1x DisplayPort

∙ 1x HDMI™ port

∙ 1x 2.5Gbps LAN (RJ45) port

∙ 4x USB 3.2 Gen 1 5Gbps Type-A ports (From Z690 chipset)

∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port (From Z690

chipset)

∙ 2x Wi-Fi Antenna connectors

∙ 6x audio jacks

I/O Controller NUVOTON NCT6687D-M Controller Chip

Hardware Monitor

∙ CPU/ System/ Chipset temperature detection

∙ CPU/ System/ Pump fan speed detection

∙ CPU/ System/ Pump fan speed control

Form Factor

∙ ATX Form Factor

∙ 12 in. x 9.6 in. (30.5 cm x 24.4 cm)

Continued on next page
