USING THE DEVICE

Power

Press the button, the appliance will start working; longly Press it (around 2-3 seconds)again, the appliance will be turned off.

Fan speed

When the appliance is working, press the button to select desired fan speed Low-Medium-High in turn.

The display will indicate the corresponding fan speed.

Timer

This appliance is equipped with a 24 hours timer.

Press TIMER button, it can be set from 1 hour to 24 hours(The time period is increased in steps of 1 hour), the display will indicate the corresponding set time, the appliance will stop automatically after the set

time has expired.

SWING

Press SWING button, the appliance will oscillate automatically for wide spread air distribution; press the SWING button again, the appliance will stop oscillation.

Wind Mode

Press the MODE button on the remote control, you can select 3 wind modes; normal, natural & sleep mode.

Cool Mode

Once you select your fan speed, press the Cool button, this will begin the water circulation and begin the cooling/humidifying/air purifying process.

1. Open the water tank lid then pour fresh water into the water tank in order to fill the internal water tank with water.

2.Check the water level carefully, stop filling when the water level reaches the ‘MAX’ mark.

DO NOT overfill the water tank otherwise permanent damage may occur to the appliance.

3. Check the water level during use to ensure that it does not fall below the ‘MIN’ mark and top up if necessary.

4. To enhance the cooling function, fill the Ice Bottles, replace the top and freeze them in the freezer. Once frozen, place one ice bottle into water tank to cool the water further.

Two ice bottles are supplied so that one can be in water tank cooling the water whilst the other is being frozen and then swapped over when

the one in the water tank has defrosted.

Ice box can store cool and slowly absorb the heating from water while ice boxes can make the temperature of water in the water tank less than it of the surrounding, so air cooler with frozen ice boxes can blow

the cooler wind.

 NOTICE: please take and put the ice boxes lightly, in order not to hurt the water recycling cooling system.

 NOTICE: do not eat ice crystals in the box, and do not use the ice crystal box as a toy for children to prevent accidental ingestion.

5. press the Cool Button and press the Fan Speed Button to select either the high, medium, or low fan speed.

DO NOT operate in the Cool mode without water in the internal water tank otherwise permanent damage may occur to the unit.

Remote control

You can operate the fan by remote control. The remote control uses 2xAAA battery (not included).NOTE: the remote control must be pointed towards the receiver on the unit. Please take out the battery for

long time no use.

CLEANING AND MAINTENANCE

 Emptying the water tank:

First turn off and unplug the unit. Place the unit either outside near a drain or alternatively on the sink drainer. Carefully lift the unit up and remove the drain bung from the bottom

of the cooler allow the water to drain out from the water tank. You can tilt the unit at several angles to make sure all water is drained out from the unit. When all the water is drained

out you can put back the drain bung. Take care not to tilt the unit over when full of water.
