Содержание
- I845ge rz 8i845ge rz c 1
- Pentiu 1
- Processor motherboard 1
- Rev 1001 12me i845gerz 1001 1
- User s manual 1
- Installing the motherboard to the chassis 3
- Preparing your computer 3
- Chapter 1 introduction 5 4
- Chapter 2 bios setup 21 4
- Chapter 3 driver installation 37 4
- English 4
- Table of content 4
- Chapter 1 introduction 5
- English 5
- Features summary 5
- English 6
- English 7
- For 8i845ge rz only for 8i845ge rz c only 7
- I845ge rz 7
- I845ge rz series motherboard layout 7
- Introduction 7 7
- Block diagram 8
- English 8
- English 9
- Hardware installation process 9
- Step 1 9
- Step 1 install the central processing unit cpu 9
- Step 2 step 4 9
- Step 3 9
- Step 4 9
- English 10
- Step 1 1 cpu installation 10
- Step 1 2 cpu cooling fan installation 10
- English 11
- Step 2 install memory modules 11
- Agp card 12
- English 12
- Game midi port 12
- Line out front speaker out 12
- Parallel port 12
- Ps 2 keyboard and ps 2 mouse connector 12
- Serial port 12
- Step 3 install agp card 12
- Step 4 1 i o back panel introduction 12
- Step 4 install i o peripherals cables 12
- Vga port 12
- English 13
- Step 4 2 connectors introduction 13
- 14 8i845ge rz series motherboard 14
- 2 atx_12v atx power connector 14
- Cpu_fan cpu fan connector 14
- English 14
- Please note a proper installation of the cpu cooler is essential to prevent the cpu from running under abnormal condition or damaged by overheating the cpu fan connector supports max current up to 600 ma 14
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector please make sure that all components and devices are properly installed align the power connector with its proper location on the motherboard and connect tightly the atx_12v power connector mainly supplies power to the cpu if the atx_12v power connector is not connected the system will not start caution please use a power supply that is able to handle the system voltage requirements it is recommended that a power supply that can withstand high power consumption be used 300w or greater if a power supply is used that does not provide the required power the result can lead to an unstable system or a system that is unable to start 14
- 12v 3 sense 15
- 15 hardware installation process 15
- English 15
- Fdd floppy connector 15
- Ide1 ide2 ide1 ide2 connector 15
- Pin no definition 15
- Please connect first harddisk to ide1 and connect cdrom to ide2 the red stripe of the ribbon cable must be the same side with the pin1 15
- Please connect the floppy drive ribbon cables to fdd it supports 360k 720k 1 m 1 4m and 2 8mbytes floppy disk types the red stripe of the ribbon cable must be the same side with the pin1 15
- Sys_fan system fan connector 15
- This connector allows you to link with the cooling fan on the system case to lower the system temperature 15
- 16 8i845ge rz series motherboard 16
- Aux_in aux in connector 16
- Connect other device such as pci tv tunner audio out to the connector 16
- English 16
- F_panel 2x10 pins connector 16
- Please connect the power led pc peaker reset switch and power switch etc of your chassis front panel to the f_panel connector according to the pin assignment above 16
- 17 hardware installation process 17
- Bat battery 17
- Caution 17
- Danger of explosion if battery is incorrectly replaced replace only with the same or equivalent type recommended by the manufacturer dispose of used batteries according to the manufacturer s instructions 17
- English 17
- F_audio front audio panel connector 17
- If you want to erase cmos 1 turn off the computer and unplug the power cord 2 remove the battery wait for 30 second 3 re install the battery 4 plug the power cord and turn on the computer 17
- If you want to use front audio connector you must remove jumpers on pins 5 6 9 10 in order to 17
- Utilize the front audio header your chassis must have front audio connector also please make sure the pin assigments on the cable are the same as the pin assigments on the mb header to find out if the chassis you are buying support front audio connector please contact your dealer please note you can have the alternative of using front audio connector or of using rear audio connector to play sound 17
- 18 8i845ge rz series motherboard 18
- Cd_in cd in connector 18
- Connect cd rom or dvd rom audio out to the connector 18
- English 18
- Please contact your nearest dealer for optional sur_cen cable 18
- Spdif_io spdif in out connector 18
- Sur_cen surround center connector 18
- The spdif output is capable of providing digital audio to external speakers or compressed ac3 data to an external dolby digital decoder use this feature only when your stereo system has digital input function use spdif in feature only when your device has digital output function be careful with the polarity of the spdif_io connector check the pin assignment carefully while you connect the spdif_io cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional spdif_io cable please contact your local dealer 18
- 19 hardware installation process 19
- Be careful with the polarity of the comb connector check the pin assignment carefully while you connect the comb cable because incorrect connection between the cable and connector will make the device unable to work or even damage it for optional comb cable please contact your local dealer 19
- Be careful with the polarity of the f_usb connector check the pin assignment carefully while you connect the f_usb cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional f_usb cable please contact your local dealer 19
- Ci chassis intrusion case open 19
- Comb comb connector 19
- English 19
- F_ usb1 f_usb2 front usb connector 19
- This 2 pin connector allows your system to detect if the chassis cover is removed you can check the case open status in bios 19
- Clr_cmos clear cmos 20
- English 20
- Pwr_led 20
- Chapter 2 bios setup 21
- Control keys 21
- English 21
- Entering bios setup 21
- Main menu 21
- Status page setup menu option page setup menu 21
- The main menu for example bios ver f1 21
- Access the hidden advanced options 22
- Advanced bios features 22
- English 22
- Exit without saving 22
- Frequency voltage control 22
- If you can t find the settings you want press ctrl and f1 in bios main menu to 22
- Integrated peripherals 22
- Load fail safe defaults 22
- Load optimized defaults 22
- Pc health status 22
- Pnp pci configurations 22
- Power management setup 22
- Save exit setup 22
- Set supervisor password 22
- Set user password 22
- Standard cmos features 22
- Top performance 22
- 23 bios setup 23
- Access mode use this to set the access mode for the hard drive the four options are chs lba large auto default auto hard drive information should be labeled on the outside drive casing enter the appropriate option based on this information 23
- Capacity capacity of currently installed hard disk 23
- Cylinder number of cylinders 23
- Day from 1st to 31st or the maximum allowed in the month 23
- English 23
- Head number of heads 23
- Ide hdd auto detection press enter to select this option for automatic device detection 23
- Ide primary master slave ide secondary master slave 23
- Ide primary secondary master slave setup you can use one of the three methods below auto allows bios to automatically detect ide devices during post default value none select this if no ide devices are used and the system will skip the automatic detection step and allow for faster system start up manual user can manually input the correct settings 23
- Landing zone landing zone 23
- Month from jan to dec 23
- Precomp write precomp 23
- Sector number of sectors 23
- Standard cmos features 23
- The format used to express time is hours minutes seconds the time is calculated based on the 24 hour military time clock for example 1 p m is 13 00 00 23
- Week from sun to sat determined by the bios and for display only 23
- Year from year 1999 to 2098 23
- Base memory 24
- Drive a drive b 24
- English 24
- Extended memory 24
- Floppy 3 mode support for japan area 24
- Halt on 24
- Memory 24
- Total memory 24
- 25 bios setup 25
- Advanced bios features 25
- Boot up floppy seek 25
- Cdrom select your boot device priority by cdrom 25
- Disabled bios will not search for the type of floppy disk drive by track number note that there will not be any warning message if the drive installed is 360k default value 25
- Disabled select your boot device priority by disabled 25
- During post bios will determine the floppy disk drive installed is 40 or 80 tracks 360k type is 40 tracks 720k 1 m and 1 4m are all 80 tracks 25
- Enabled bios searches for floppy disk drive to determine if it is 40 or 80 tracks note that bios can not tell from 720k 1 m or 1 4m drive type as they are all 80 tracks 25
- English 25
- First second third boot device 25
- Floppy select your boot device priority by floppy 25
- Hdd 0 3 select your boot device priority by hdd 0 3 25
- Lan select your boot device priority by lan 25
- Ls120 select your boot device priority by ls120 25
- Note 1 this option appears only when the intel pentiu 25
- Prescott processor note 3 4 this option is available only when you use the onboard vga function 25
- Processor you install on the system supports the hyper threading technology note 2 this option is available only when you install an inte 25
- Scsi select your boot device priority by scsi 25
- Usb cdrom select your boot device priority by usb cdrom 25
- Usb fdd select your boot device priority by usb fdd 25
- Usb hdd select your boot device priority by usb hdd 25
- Usb zip select your boot device priority by usb zip 25
- Zip select your boot device priority by zip 25
- Cpu hyper threading 26
- English 26
- Graphics aperture size 26
- Graphics share memory 26
- Init display first 26
- Limit cpuid max to 3 26
- Password check 26
- English 27
- Ide1 conductor cable 27
- Ide2 conductor cable 27
- Integrated peripherals 27
- On chip primary pci ide 27
- On chip secondary pci ide 27
- Usb controller 27
- Ac97 audio 28
- English 28
- Onboard h w lan 28
- Onboard lan boot rom 28
- Onboard parallel port 28
- Onboard serial port 1 28
- Onboard serial port 2 28
- Parallel port mode 28
- Usb keyboard support 28
- Usb mouse support 28
- 29 bios setup 29
- Acpi suspend type 29
- Blinking the power led will be blinking during s1 state default value 29
- Disabled disable this function 29
- Disabled disable this function default value 29
- Dual off the power led will be turned off or change color 29
- Ecp mode use dma 29
- Enable this function and set gameport address to 201 default value 29
- Enable this function and set gameport address to 209 29
- Enable this function and set midiport address to 300 29
- Enable this function and set midiport address to 330 29
- English 29
- Game port address 29
- Midi port address 29
- Midi port irq 29
- Power led in s1 state 29
- Power management setup 29
- S1 pos set acpi suspend type to s1 default value 29
- S3 str set acpi suspend type to s3 29
- Set ecp mode use dma to 1 29
- Set ecp mode use dma to 3 default value 29
- Set midiport irq to 10 default value 29
- Set midiport irq to 5 29
- This feature allows you to select direct memory access dma channel if the ecp mode selected this option is available only when parallel port mode is set to ecp or ecp epp 29
- This option is available when the midi port address is not set to disabled 29
- Ac back function 30
- English 30
- Kb power on password 30
- Modemringon 30
- Pme event wake up 30
- Power on by keyboard 30
- Power on by mouse 30
- Resume by alarm 30
- Soft off by pwr bttn 30
- 31 bios setup 31
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 1 5 31
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 2 31
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 3 31
- Auto auto assign irq to pci 1 5 default value 31
- Auto auto assign irq to pci 2 default value 31
- Auto auto assign irq to pci 3 default value 31
- Auto auto assign irq to pci 4 default value 31
- English 31
- Pci1 5 irq assignment 31
- Pci2 irq assignment 31
- Pci3 irq assignment 31
- Pci4 irq assignment 31
- Pnp pci configurations 31
- Case opened 32
- Cpu system fan fail warning 32
- Cpu warning temperature 32
- Current cpu system fan speed rpm 32
- Current cpu temperature 32
- Current voltage v vcore 3 v ddr25v 12v 32
- English 32
- Pc health status 32
- Reset case open status 32
- 33 bios setup 33
- Auto set memory frequency by dram spd data default value 33
- Auto set memory frequency by dram spd data default value for fsb front side bus frequency 533mhz 33
- Cpu clock ratio 33
- Cpu host clock control 33
- Cpu host frequency mhz 33
- Disabled disable cpu host clock control default value 33
- Enabled enable cpu host clock control 33
- English 33
- Fixed pci agp frequency 33
- For fsb front side bus frequency 400mhz 33
- Frequency voltage control 33
- Host dram clock ratio 33
- Incorrect using these features may cause your system broken for power users only 33
- Memory frequency host clock x 2 33
- Memory frequency host clock x 2 6 33
- Mhz 355mhz set cpu host clock from 100mhz to 355mhz if you use a pentium 4 cpu with fsb 533mhz please set cpu clock to 133mhz for a p4 cpu with fsb 400mhz please set it to 100mhz inappropriate using it may cause your system corrupted for power end user use only 33
- Please note that if your system is overclocked and cannot restart please wait 20 secs for automatic system restart or clear the cmos setup data and perform a safe restart 33
- This item will be available when cpu host clock control is set to enabled 33
- This setup option will be automatically assigned by cpu detection the option will display locked and read only if the cpu ratio is not changeable 33
- You can choose those modes to adjust pci agp frequency select pci agp frequency asynchronous with cpu frequency 33
- 34 8i845ge rz series motherboard 34
- Disabled disable this function default value 34
- Enabled enable top performance function 34
- English 34
- Fail safe defaults contain the most appropriate values of the system parameters that allow minimum system performance 34
- If you wish to maximize the performance of your system enable top performance 34
- Load fail safe defaults 34
- Memory frequency mhz 34
- Pci agp frequency mhz 34
- The values depend on cpu host frequency 34
- The values depend on fixed pci agp frequency 34
- Top performance 34
- Top performance will increase h w working speed different system configuration both h w component and os will effect the result for example the same h w configuration might not run properly with windows xp but works smoothly with windows nt therefore if your system is not perform enough the reliability or stability problem will appear sometimes and we will recommend you disabling the option to avoid the problem as mentioned above 34
- 35 bios setup 35
- English 35
- Load fail safe defaults 35
- Load optimized defaults 35
- Selecting this field loads the factory defaults for bios and chipset features which the system automatically detects 35
- Set supervisor user password 35
- When you are prompted to enter password a message password disabled will appear to confirm the password being disabled once the password is disabled the system will boot and you can enter setup freely the bios setup program allows you to specify two separate passwords supervisor password and a user password when disabled anyone may access all bios setup program function when enabled the supervisor password is required for entering the bios setup program and having full configuration fields the user password is required to access only basic items if you select system at password check in advance bios features menu you will be prompted for the password every time the system is rebooted or any time you try to enter setup menu if you select setup at password check in advance bios features menu you will be prompted only when you try to enter setup you try to enter setup 35
- 36 8i845ge rz series motherboard 36
- English 36
- Exit without saving 36
- Save exit setup 36
- Type y will quit the setup utility and save the user setup value to rtc cmos type n will return to setup utility 36
- Type y will quit the setup utility without saving to rtc cmos type n will return to setup utility 36
- Chapter 3 install drivers 37
- English 37
- Install drivers 37
- Revision history 37
- English 38
- Item description 38
- 39 contact us 39
- Contact us 39
- English 39
- 40 8i845ge rz series motherboard 40
- English 40
Похожие устройства
- Sdmo K10M-IV Инструкция по эксплуатации
- Western Digital My Cloud EX2 0TB ( Инструкция по эксплуатации
- Gigabyte GA-8VM800PMD-775 Инструкция по эксплуатации
- Sdmo K10M-IV с АВР Инструкция по эксплуатации
- Philips S9511/41 Инструкция по эксплуатации
- Sdmo T12K Инструкция по эксплуатации
- Tefal BALAI AIR FORCE EXTREME Li-Ion TY8875RO Инструкция по эксплуатации
- Sdmo T12K с АВР Инструкция по эксплуатации
- Gigabyte GA-8IP775 Инструкция по эксплуатации
- Bork AU501 Инструкция по эксплуатации
- Sdmo T12K-IV M126 Инструкция по эксплуатации
- Gigabyte GA-8I945P-G Инструкция по эксплуатации
- Sdmo T12K-IV M126 с АВР Инструкция по эксплуатации
- Runtastic RUNGPS1 Инструкция по эксплуатации
- Sdmo T12HK Инструкция по эксплуатации
- Gigabyte GA-8I945GMF Инструкция по эксплуатации
- Philips S9151/31 Инструкция по эксплуатации
- Sdmo T12HK с АВР Инструкция по эксплуатации
- Sdmo T12HK M125 Инструкция по эксплуатации
- Gigabyte GA-8I915P-G Инструкция по эксплуатации
