- 11 - Hardware Installation
IEEE 1394
w
T.I. TSB43AB23 chip
- Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394a
bracket connected to the internal IEEE 1394a header)
Internal
w
1 x 24-pin ATX main power connector
Connectors
w
1 x 8-pin ATX 12V power connector
w
1 x oppy disk drive connector
w
1 x IDE connector
w
7 x SATA 3Gb/s connectors
w
1 x CPU fan header
w
2 x system fan headers
w
1 x front panel header
w
1 x front panel audio header
w
1 x CD In connector
w
1 x S/PDIF In header
w
1 x S/PDIF Out header
w
3 x USB 2.0/1.1 headers
w
1 x IEEE 1394a header
w
1 x serial port header
w
1 x clearing CMOS jumper
Back Panel
w
1 x PS/2 keyboard/mouse port
Connectors
w
1 x D-Sub port
(Note 2)
w
1 x DVI-D port
(Note 2) (Note 3) (Note 4)
w
1 x optical S/PDIF Out connector
w
1 x HDMI port
(Note 2) (Note 4)
w
1 x DisplayPort
(Note 2) (Note 4)
w
4 x USB 2.0/1.1 ports
w
2 x USB 3.0/2.0 ports
w
1 x IEEE 1394a port
w
1 x eSATA 3Gb/s connector
w
1 x RJ-45 port
w
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/
Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
w
iTE IT8720 chip
Hardware Monitor
w
System voltage detection
w
CPU/System temperature detection
w
CPU/System/Power fan speed detection
w
CPU overheating warning
w
CPU/System/Power fan fail warning
w
CPU/System fan speed control
(Note 6)
