- 11 - Hardware Installation
Storage Interface 2 x Marvell 88SE9128 chips:
- 2 x SATA 6Gb/s connectors (GSATA3_6, GSATA3_7) supporting up to 2
SATA 6Gb/s devices
- Support for SATA RAID 0 and RAID 1
- 2 x eSATA 6Gb/s connectors (eSATA/USB Combo) on the back panel
supporting up to 2 SATA 6Gb/s devices
- Support for SATA RAID 0 and RAID 1
USB Chipset:
- Up to 8 USB 2.0/1.1 ports (4 on the back panel, including 2 eSATA/USB
Combo, 4 via the USB brackets connected to the internal USB headers)
2 x Renesas D720200 chips and 2 x VLI VL810 hubs:
- Up to 10 USB 3.0/2.0 ports (6 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
* The USB 2.0 signals of the 6 USB 3.0/2.0 ports on the back panel are from the
Chipset.
IEEE 1394 T.I. TSB43AB23 chip:
- Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394a bracket
connected to the internal IEEE 1394a header)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
4 x SATA 3Gb/s connectors
1 x CPU fan header
3 x system fan headers
1 x power fan header
1 x Chipset fan header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 2.0/1.1 headers
2 x USB 3.0/2.0 headers
1 x IEEE 1394a header
1 x clearing CMOS button
1 x power button
1 x reset button
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x optical S/PDIF Out connector
1 x coaxial S/PDIF Out connector
2 x IEEE 1394a ports
2 x USB 2.0/1.1 ports
6 x USB 3.0/2.0 ports
2 x eSATA/USB Combo connectors
2 x RJ-45 ports
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker
Out/Line In/Line Out/Microphone)
