- 11 - Hardware Installation
USB South Bridge:
- Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
1 x Renesas D720200 chip and 2 x VLI VL810 hubs:
- Up to 8 USB 3.0/2.0 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
* The USB 2.0 signals of the USB 3.0/2.0 ports are from the South Bridge.
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
2 x 4-pin PCIe 12V power connectors
2 x SATA 6Gb/s connectors
6 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
3 x fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 2.0/1.1 headers
2 x USB 3.0/2.0 headers
1 x clearing CMOS jumper
1 x Quick Boost button header
1 x heatsink LED power connector
Back Panel
Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x optical S/PDIF Out connector
1 x coaxial S/PDIF Out connector
4 x USB 2.0/1.1 ports
4 x USB 3.0/2.0 ports
1 x RJ-45 port
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker
Out, Line In/Mic In, Line Out)
I/O Controller iTE IT8720 chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
BIOS 2x16Mbitash
Use of licensed AWARD BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
