4 Usage and Storage Instructions EN
EN
ASSEMBLING SEQUENCE
The only tool necessary for assembling the appliance is a
cross head screwdriver (not included in the set).
1. Support column and base: Remove the L-shape
screw and metal ring from the support column. Attach
the height adjustment rod and support column to
the fan base by screwing the L-shape screw through
the base to the mounting bracket at the end of the
support column. Loosen or tighten height adjuster to
change the height of the fan .
2. Installing the control box.
Do not pull out the stopper of the inner pipe!
If you pull it out it may need repair.
Do not ever loosen the screw of the inner pipe!
•
Loosen the screw of the control box by turning
it to the left.
•
Place the hole in the lower end of the control
box onto the inner pipe.
•
Turn the screw of the control box clockwise and
tighten it rmly.
3. Installation of the front part of the fan.
•
Install the rear protection cover onto the motor
and prop it up with the locking nut.
•
Pull the blade over the motor axis. Tighten the
blade with its cap.
•
Installation of front protective grill with spoke.
Rotate the front protective cover so that the
trade mark on it is horizontal and put on the
back protective cover. Connect them as press
their countries so that both protective cover to
be xed by the outer plastic chutes .
•
Secure by using screw – outer plastic chute,
locking front and rear protective grill.
Do not ever use a fan with a cracked or
damaged blade!
The appliance is designed to be used only
standing on the oor!
USE
Speed control
The speed of the fan is controlled by buttons. For
switching the fan on, press any of the speed buttons (1-
2-3). For switching the fan o, press the “O” button.
Oscillation
Press down the oscillation button and the
fan will start rotating sideways. Pull the
button and the oscillation will stop.
Adjustment of the tilting position
The airow can be directed upwards or
downwards by moving the protection
cover up or down.
Always switch the fan o before adjusting
its tilting position.
Height adjustment
Loosen the screw for height adjustment, then position
the pipe at the desired height and tighten the screw
again.
Timer – the fan is tted with a 60-minute timer. It
has 2 positions – for working mode (ON) or stopping
(OFF). When it is on, its task is to switch o the fan in
60 minutes time at the latest; when it is o it does not
aect the work of the fan.
PACKING
•
After unpacking the appliance make sure it is not
damaged during transportation and that it is fully
tted. In the event of damage or missing parts,
contact your authorized seller!
•
Do not throw away the original box. It can be used
for storage and transportation, for avoiding damage
during transportation!
•
Dispose of the packing materials in a proper way!
Keep children away from the polyethylene bags!
