Benq LCD Color Monitor User's Guide
English 37
Press “Enter” to enter adjustment menu. Use fly wheel to adjust horizontal display posi-
tion and then press “Exit” to return to main menu.
Press “Enter” to enter adjustment menu. Use fly wheel to adjust vertical display position
and then press “Exit” to return to main menu.
Press “Enter” to enter adjustment menu. Use fly wheel to adjust phase and then press
“Exit” to return to main menu.
3. Horizontal Position
4. Vertical Position
5. Phase
