30 How to adjust your monitor
H. Position
Adjusts the horizontal
position of the OSD menu.
Press the t or u keys to
adjust the value.
0 to 100
V. Position
Adjusts the vertical posi-
tion of the OSD menu.
0 to 100
Display Time
Adjusts the display time of
the OSD menu.
• 5 sec.
• 10 sec.
• 15 sec.
• 20 sec.
• 25 sec.
• 30 sec.
OSD Lock
Prevents all the monitor
settings from being acci-
dentally changed. When
this function is activated,
the OSD controls and hot-
key operations will be dis-
abled.
Press the t or u keys to
change the settings.
To unlock the OSD
controls when the OSD is
preset to be locked, press
and hold the 'Menu/Exit'
button for 15 seconds to
enter the 'OSD Lock'
option and make
changes.
• ON
• OFF
Press Menu/Exit to leave the OSD Settings menu.
Information
Displays the current moni-
tor property settings.
Press the Enter key to select
this option.
Reset All
Resets all mode, color and
geometry settings to the
factory default values.
Press the
t or u keys to
change the settings.
• Ye s
• No
