· Futuristic Design

· 2.85" Customizable HD Display

· Carbon Fiber Reinforced Composite

· 16.7M Color RPM Lights

Method A:

· Align the 6 ball bearings on the wheel QR with the 6 notches on the base QR mount.

· Press the quick release onto the base mount, keeping the bearings and notches aligned.

· The quick release will automatically lock into place; if it doesn’t, then remove it, recheck

the alignment and try again.

· To remove the wheel, squeeze the black quick release part with the MOZA logo towards

the wheel with both hands and pull out the wheel at the same time.

Method B:

· Rotate the wheelbase until you locate the arrow directly above the base.

· Center the wheel and attach it to the wheelbase.

· To remove the wheel, use both hands to squeeze the black quick release part with the

MOZA logo towards the wheel with both hands and pull out the wheel at the same time.

The wheel can be set up quickly and easily using MOZA Pit House software.

· Clutch paddle modes: Can be set to composite axis, independent axis, or button.

· Joystick modes:Can be set to button or D-pad.

· RPM indicator switch modes:Choice of rpm, off and constant.

Product Features

QR Use Guide

Steering Wheel Configuration

The shifter paddle

mounting hole is

elongated to allow the

paddle distance to be

adjusted.

· Hall Sensor Magnetic Paddle with Dual Clutch

· Programmable Short Travel RGB Buttons

· All-aluminum Quick Release

· Direct Connection to PC

A B
