28
Storing and maintenance
Maintain your lawnmower on a regular basic:
Check all bolts, screws and deck. Always make sure the knife is sharp. It is
recommended that the knife is changed every 2 years.
It is a good idea to let your local service shop check your lawnmower once a year.
Storing: Keep the lawnmower in dry clean room. Clean the machine every time it
has been used. Grass and dirt must be removed from the inside of the cutting deck.
Tilt the front of the lawnmower for cleaning, maximum 45 degrees. If you tilt it to the
side, the carburettor and air filter must always turn up. If it does not turn up, the oil
may run out and damage the engine. Always make sure the cap is removed from
the spark plug when the lawnmower is being maintained.
Winter storage: Empty the fuel tank and let the engine run until there is no fuel left.
Remove the cap for the spark plug.
Remove the spark plug and add one tablespoon of oil in the hole. Pull the starting
cord several times. Mount the spark plug, but not the cap.
Change oil according to the above chapter
Finally the lawnmower is cleaned. Remove all the dirt and grass from everywhere.
Dip a cloth in oil and cover the deck and handle in a thin layer of oil, to keep it from
rusting.
Warranty
• 2 years of warranty is given on your lawnmower.
• The warranty covers material and/ or fabrications faults.
• The warranty does not cover damages, which has occurred because of tear, bad
use and lack of maintenance.
• The warranty does not cover cleaning of the fuel system, exchange/adjust of the
starter cord, starting spring, spark plug, knife, knife holder, belt, battery and cables.
• The warranty does not cover if unoriginal spare parts have been used.
• It is always a service shop, which decides if a case is a warranty claim, or not.
• Your receipt is your warranty note. Always keep it.
Remember: The engine number and the model must always be given to the shop
when spare parts are purchased.
Technical specifications
Model
SP 50 TR/WE XT 50 TR/WE
Engine Powerline TG575 (173 cc) Powerline TG675 (200 cc)
Drive Self-propelled - big wheel Self-propelled - big wheel
Cutting width
50 cm 50 cm
Height adjustment Central - 7 positions 25-75 mm Central - 7 positions 25-75 mm
Deck Steel Steel
Cutting system 3 in 1 4 in 1
